ZTW Mantis Slim 80A SBEC 8A Brushless ESC Speed Controller For RC Models
Mantis Slim is a high quality esc with complete product line, reliable performance. It contains 15A, 30A, 40A, 60A, 80A seven models from low to high voltage.
Small and light, special for F3P and glider. The total 5 models esc were designed light, 6.8g only (without cable) for 15A. Light weight leave much adjust room to keep balance for frame. Mantis slim series ESC are special for F3P and glider.
Specification:
Product Model Mantis Slim 80A SBECModel Number 2080271Typebrushed/brushlessbrushlessãHigh Voltage / NormalNormalSpecificationsContinuous Current80AãBurst Current100AãBattery Cell5-18NC/2-6LipoãBEC output5.5V/8ASizeWidth29mmãLength60mmãHeight14.5mmãWeight57gWires & ConnectorsPower Wires12 AWG, 100mm-Red/100mm-BlackãMotor Wires12 AWG, 100mm-BlackãSignal Wires(Brownorange and red) 60C, 330mm a special JR male plug at one sideãPower plug noESC Programing viaTransmitteryesãAIR Program CardyesãLED Program CardããLCD Program CardããWiFi ModuleããUSB program connectorãFirmwareFirmware UpgradeãProgrammable Item/TonesOption Throttle Calibration (within the first 4 Sec )ââ ââ ââ ââ1 Brake _ * _ * _ * _ * Brake On /Off2 Battery type ~ ~ ~ ~ NiCad ~ ~ ~ ~ ~ ~ ~ LiPo3 Low Voltage Cutoff Threshold *_ _* *_ _* *_ _* *_ _* Low2.8V/50% *_ _ _* *_ _ _* *_ _ _* *_ _ _* Medium3.0V/60%*_ _ _ _* *_ _ _ _* *_ _ _ _* *_ _ _ _* High3.2V/65%4 Restore Factory Setup Defaults — — — — Restore5 Timing Setup – – – – Automatic (7-30°) – – – – – – – – Low (7-22°) – – – – – – – – – – – – High (22-30°)6 Acceleration ∨∨ ∨∨ ∨∨ ∨∨ Soft ∨ ∨ ∨ ∨ Normal ∨∨∨ ∨∨∨ ∨∨∨ ∨∨∨ Hard7 Heli Mode _*_ _*_ _*_ _*_ Rpm off _**_ _**_ _**_ _**_ Heli Mode 1 _***_ _***_ _***_ _***_ Heli Mode28 Motor Rotation W W W W Forward/ Reverse9 Switching Frequency // // // // 8kHz \ \ \ \ 16kHz10 Low Voltage Cutoff Type - - - - Reduce Power - - - - Hard Cut OffããDefaultBrake: OFF
Battery type Detect: LiPo with Automatic Cell
Low voltage Cutoff threshold: Medium (3.0V/60%)
Timing Setup: Automatic
Acceleration: Soft Acceleration
Heli Mode: RPM OFF
Motor Rotation: Forward
Frequency: 8kHz
Low Voltage Cutoff Type: Reduce power
Features:
* BEC built-in, easy to control.
* Great quality, reliable performance.
* Program card from Beatles.
* Protect your beloved planes.
* Over temperature protection.
* Electrify safety.
Package Included:
1X ZTW Mantis Slim 80A SBEC
