XXD 2212 1400KV Motor+HW30A ESC+K-power Servos+Propeller
Motor Specification:
Brand Name: XXD
Item Name: XXD A2212 KV1400 Brushless Motor
Item NO.: XXD A2212
Dimensions: 27.8*27mm
Shaft Diameter: 3.17mm
Max Efficiency: 80%
Max Efficiency Current: 4-10A (>75%)
Current Capacity: 12A/60s
No Load Current @ 10V: 0.5A
No. Of Cells: 2-3 Li-Poly
Weight: 47g
KV: 1400
ESC Specification:
Package Included:ESC Specification:
Brand Name: XXD
Power input: 5.6V - 16.8V (2-3 cells Li-Poly, OR 5-12 cells Ni-MH Ni-MH / Ni-Cd battery)
BEC: 2A
Constant current: 30A (Max 40A less than 10 seconds)
Weight: 25g
Dimensions: 45 x 24 x 11mm
Quantity:4
Features:
Safe power function:regardless of the throttle stick in any position the motor will not start immediately
Throttle Calibration function:Adapt to different remote throttle travel difference, improve throttle response linearity, with a smooth, delicate feel and excellent speed linear speed
Low Voltage Protection Mode ,Low-voltage protection threshold
Servo Specification:
Servo Specification:
Brand Name: K-Power
Item Name: P0090
Color: Blue
Weight (grams): 9g
Size: About 32 x 12 x 30mm
Servo Motor Type: Brushless 3 pole
Bearing Type: None
Gear Type: Plastic POM
Servo Case: Hard Plastic
Wire Length (cm): 27
Voltage: 4.8V-6.0V
Speed (6.0v) sec/60°: 0.09
Speed (4.8v) sec/60°: 0.1
Torque (6.0v) kg-cm: 1.8
Torque (4.8v) kg-cm: 1.6
Dead Band Width: 8 usec
Neutral Position: 1500 usec
Usage: Used for RC small planes, helis, boats
Features:
Perfect Low Budget with High Quality servo in 9 grams weight.
Use Metal Gear for Motor and Plastic POM material for other gears.
Has 270mm servo cable (no need to add servo cable extension)
Has TRUE data, easily run at Stall Current at 2.0Amps in 6.0 Volts.
1x XXD 2212 1400KV Motor
1 x XXD HW30A ESC
2 x K-power P0090 Servos
2 x EP8060 Propellers
1 x Motor Holder
3 x Spanners
