XP-12A Linear Brushless ESC For Walkera 4#3/4G3/4G6/V120D
Description:
Name:XP-12A Brushless ESC
Input voltage : 3V-13V ( support section 1-3 lithium battery )
Dimensions ( length x width x thickness ): 22x17x7 mm
Burst current: 15A ( less than 10 seconds )
BEC output: 1A/5V ( linear mode )
Continuous Current: 12A
Weight: 8 g
Feature:
1.Very good low-speed performance.
2.Built-in linear BEC or switch mode BEC.
3.The use of high-speed, small size MCU, and powerful.
4.3 throttle curve to choose from. Motor reversal can be set.
5.The programming card with LCD display , convenient and intuitive.
6.Throttle range can be configured to be compatible with different receivers.
7.Up to speed:240,000 rpm ( 2 poles ),80,000 rpm ( 6 poles ) and 40,000 ( 12 poles ).
8.7 A,12A ESC supports a lithium battery, the minimum operating voltage as low as 3V.
9.The governor of multiple parameters can be programmed card or remote control settings.
10.There is a very good starting performance,great throttle linear and quick throttle response.
11.MCU and BEC different regulator, independent of each other and improve the anti-jamming capability.
12.Low voltage protection threshold and start- power cards can be programmed to quantify precisely set .
13.With low voltage protection,over-temperature protection,throttle signal lost protection,motor starter protection,post and so on.
14.Starting gently for 4 seconds super soft start function helicopters. When starting the helicopter , no significant impact and drift phenomena.
Package include:
1 x XP-12A Brushless ESC
