Description:
Item Name: X240 Mini Quadcopter
Weight: About 500g
Size: 18*13*10cm
Motor: A1510 Motor
ESC: Hobbywing X-rotor 10A OPTO
Flight Controller: CC3D with protective case and shock damper
Propeller: 5045 3-Leaf Propeller
Mini Frame:
Weight: 78g
Weight: 78g
Material: Glass Fiber
Upper Board: 1.0mm
Lower Board: 1.5mm
Wheelbase: 240mm
Motor:
Brand Name: XXD
Brand Name: XXD
KV: 2200
Size: Φ18mm x 17.5mm (Not included shaft)
Weight: 16.1g/0.57oz
Output Shaft Diameter: Φ2mm
Output Shaft Length: 8mm
Internal resistance: 0.52 Ω
Maximum Efficiency Current: 2A to 6A, >70%
Maximum Operating Current: 8.5A
IO: 0.5A/10V
Features:
ESC:
Brand Name: Hobbywing
Brand Name: Hobbywing
Input:2-3S Lipo
Persistent Current:10A
Instantaneous Current: 15A(10 second)
Size: 36.5*16.4*4.1mm
Weight: 6.5g
BEC Output: None
Plug: 2.0mm Banana Plug
Programmable Item: TimingHigh/Intermediate)
CC3D flight controller
With Li-ion battery low voltage alarm
Included power distribution board(with BEC)
Banana plug has been welded on motor and ESC.
Ready to fly,just need to buy the transmitter(receiver)and battery
Inlcuded other assemble accessories,like nylon cable and magic type.
Notice: This Set not included transmitter,receiver and battery.
CC3D CopterControl Hardware Features:
Powerful STM32 32-bit microcontroller running at 90MIPs with 128KB Flash and 20KB RAM.
3-axis high-performance MEMs gyros and 3-axis high-performance MEMs accelerometer.
Tiny 36mmx36mm 4 layer PCB for superior electrical noise reduction and flight performance.
Software support for Windows, Mac and Linux.
Direct high speed USB support with no drivers required, a truly plug and play device.
Spektrum satellite receiver support.
Futaba S-BUS hardware support.
Innovative Flexi-port technology for superior port flexibility.
4Mbits on-board EEPROM for configuration storage.
Parts recommended (package not included)
YKS BW140 11.1V 1300MAH 3S battery, please .
Walkera DEVO 7 2.4GHz Transmitter
FlySky FS-i6 2.4G 6CH AFHDS RC Transmitter With FS-iA6 Receiver, .
Package included:
1 x X240 Frame Kit
1 x CC3D flight controller
4 x A1510 Motor
4 x Hobbywing X-rotor 10A OPTO ESC
3 x 5045 3-blade Propeller Pair
1 x Power Distribution Board
1 x Li-ion battery low voltage alarm
