Walkera F210 5.8G FPV HD Camera SP Racing F3 Flight Control Racing Drone with DEVO7
Note:The drone is total with 1 battery . Due to the logistics limit, the battery is not allowed to be shipped with the product.
We have to take it out and deliver it separately as a gift.
Walkera F210 Racing Drone Flight Test Review
Specification: User Manual
Brand Name: Walkera
Item Name: F210 Racing Drone
Model: F210
Version: Devo7 Right Hand Throttle, Devo7 Left Hand Throttle and BNF Version
Aircraft:
Main Rotor Dia:128mm
Overall Dimension:182x182x103mm
Weight:370g(Battery included)
Remote Controller:DEVO 7
Receiver:DEVO-RX713
Main Controller:FCS-F210(F3)
Transmitter :TX5825(FCC)/TX5824(CE)
OSD : F210 OSD
Brushless Motor WK-WS-28-014A(CW/CCW)KV2500
Brushless ESC F210(CW/CCW)
Battery:14.8V 1300mAh 40C 4S Li-PO
Flight Time:8~9mins
Working environment : -10â ~ +40â
Camera(700TVL):
Horizontal Resolution:700TVL
System Commitee:PAL/NTSC
Video Out:1.0Vp-p/75Ω
Power Input: DC 12V
TX5825(FCC)/TX5824(CE) Transmitter:
5.8G wireless:Image transmission
TX5825(FCC) Bind B section:4 channels
TX5824(CE) Bind B section:4 channels
TX5825(FCC) output power:≤200mW
TX5824(CE) output power:≤25mW
Features:
-Night Sight HD Camera
-Centralized Control System Design
-SP Racing F3 Flight Control
-Metallic Case Design
-Powerful Motor Design
Package Included:
Devo7 Right Hand Throttle Version:
1x Walkera F210 Racing Drone
1x 700TVL Camera
1x OSD
1x Transmitter
1x Receiver
1x DEVO 7 ( Right Hand Throttle)
1x Battery
1x Power Adapter
Devo7 Left Hand Throttle Version:
1x Walkera F210 Racing Drone
1x 700TVL Camera
1x OSD
1x Transmitter
1x Receiver
1x DEVO 7 ( Left Hand Throttle)
1x Battery
1x Power Adapter
BNF Version:
1x Walkera F210 Racing Drone
1x 700TVL Camera
1x OSD
1x Transmitter
1x Receiver
1x Battery
1x Power Adapter
