The Ranger EX is a airplane is specially designed for Long Range FPV and quick and very easy trouble free Setup of this great big Bird. FPV Ranger EX offers few greater qualities that every FPV pilot looks forward to have in his / her RC FPV Plane.
1.It has bigger tougher PVC Fuselage that makes this plane a crash resistant plane, Tons of open space to let bigger hands do their job inside the fuselage when it comes to mount the electronics inside and also this big place makes it possible for one to mount more gear inside and keep things neat.
2.Ability to carry more payload means one can mount higher mAh batteries to get ultra long flight times needed for those long range FPV flights you are going to do
3.Tall Landing gear and dragger wheel means you can now safely take off and land from ground. No need to hand launch a big heavy plane with all the gears and dangerous and sharp propeller spinning at the back
4.Easy mounting of Various Brushless gimbals for GoPro 3 under the nose, now you can take ultimate stable flight videos of your long range flights
5.Super easy few step setup and glue free assemble.
Description:
Wingspan: 1980mm (77.9 in)
Overall Length: 1170mm (46 in)
Flying Weight(without battery): 1500g
Prop Size: 1060 Propeller
Motor Size: 3715/1200KV powerful out runner brushless motor
Speed Control : Easy-Plug 40A Switch-mode BEC brushless ESC
Servo 9-gram Servo * 6pcs included
Recommended Battery: 11.1V/14.8V 1800mAh ~ 10000mAh Li-Po
Charger: Not included
Flaps: Yes
Retracts: No
Radio: 2.4Ghz 6-Channels
Minimum Age Recommendation: 14 years
Experience Level: Beginners ~ Expert
Recommended Environment: Outdoor
Assembly Time: Less than half hour
Is Assembly Required: Yes
This one is plane frame kit+ propeller(landing gear included) only.
Key Features:
Big space, durable UNIBODY design
Special airfoil design for carrying big weight
Compatible with most kind of camera mounting
Capability to carry Camera Gimbal
Quick, easy to assembly, no glow required
Light weight and durable EPO wing construction
FPV System Deployment
Special design and optimize for long range FPV, so there is a lot of space for mounting systems and different Camera mounting way, which not require any modify.
Easy for All kind if camera mounting
Are you tired of modification a lot to mount your camera well? Now you don’t have to.We consider a lot kind of mounting for you, you can easy to mount it as better as you like. Stable, safe, and easy, just focus to make a wonderful video and enjoy it.
Easy for FPV camera mounting
Considering for professional FPV traveling, usually you will need a full HD camera and another FPV camera for Video transmission, so we leave a very convenient, safe, good view space for you to mount a FPV camera, just enjoy it.
Special fuselage design
The whole unibody fuselage is produced by our copyright one-step moulding technology, which make it more durable and strong than other EPO foamy carbon tube. So it can avoid the tail effected by the air and cause the bump during the flight.
Special small platform in the tail is builded for video TX installation, can leave away from the radio equipment avoid causing nosy. In the same time the propeller can cool down it from over heat.
Gradienter preinstalled
We are thinking much more than others, for UAV system setup, to calibrate the sensors in horizontal level is very very importance. So the gradienter in the wing CG position will help a lot to setup the system.
Very big space for big batteries
The very importance point for a airplane which can travel long range or not, should be the big batteries carrying ability. Thanks to our unibody technology, we have much more a lot space than other foamy plane to carry almost twice capacity batteries. Of course we still have a lot more space for equipment, and sure we have lot more space for cooling down the battery.
Package included:
1 x Volantex Ranger EX RC Airplane PNP
