UNRC MAX5A 1-6S RC LiPo Battery 8 Interface Power Supply For UN A6
Description:
Brand Name: UNRC
Item Name: MAX5A lipo battery power supply
Size: 167mm x 84.6mm x 36mm
Weight: 320g
Maximum Charging Current: 5A
Support Charging method: 24 x 2S , 16 x 3S or 8 x 6S Li-Po batteries
Charging Method: Alternatively charging
Other function: Discharging (discharging voltage can be set, 0.01V stepping)
Requirment: Must work with UN-A6 charger
Note: If customers need to charge with large current, make sure to use the switch supply with proper power
Features:
- The latest design array voltage driving circuit is very good replaced relay does not exist switch life.
- Lossless transmission design, using a low resistance of MOS tube sheet resistance only only six milliohm and reduce the transmission pressure drop can realize large current charging,power supply can directly tow 5A above the charging current.
- Support multiple groups of battery, 2s 24 groups, 3s 16 group, 6s 8 group.
- The new circuit and process greatly reduce the volume.
- Add professional discharge circuit can access all of the battery every cell separate discharge, can balance the voltage unbalance of the battery.
- Configurable discharge voltage (1.5 V to 4.2 V, 0.01 V stepping), can be installed freely.
- Open-and-shut working state, light panel is equipped with switch group, put circuit instructions, internal anti joint protection, reverse connect the battery will not cause damage,
- Add the charger patrol function to UN charger for safety monitoring if found charger doesn't work properly 5 seconds cut off all battery, prevent accident.
- Reserve two kinds of data input interface, compatible UN - A6 new and old version firmwares, (only new version firmware can drive discharge function).
- No button design automatically detects data line input port.
How To Use:
- Connection Method. For the new version in1 A6 data interface, in2 for old version A6 data interface and can be compatible with other charge, inout and charger of charging outlet connections, 1 ~ 8 for battery interface.
- Charging Mode. The cable connected to the charger and charging output, switch on the power,the UN - A6 charging mode set to 2 can drive power supply in infinite time of the battery scanning,when detected a battery meets the charging requirements,will stop scanning and begin to charge,the charging group indicator light will be normal on.If charging completed will jump to the next group,until all the connected batteries are full of charge.
- Discharge Mode. The cable connected to the charger and charging output, switch on the power,the UN - A6 charging mode set to 3 can drive power supply scan the battery for unlimited time,when detected a battery meets the discharging requirements,will stop scanning and begin to discharge,the discharging group indicator light will be normal on,and you can see the discharge light is lit up. Six discharge indicator lights is corresponding to each cell batteries discharge state.If discharging completed will jump to the next group,until all the connected batteries complete discharge.
- Starting Protection. If for some reason cause the charger doesn't work or work abnormal, data port send out wrong data,the power supply will start time,if more than 5 seconds without correct data output power supply will cut off all of the battery pack,remove all of the discharge group to ensure safety.
Package Included:
1x UNRC MAX5A charger power supply
