Ublox NEO-M8N GPS Module For PX4/PIX4 APM2.6/2.8 Mini APM Built-in Compass
The under pictures are for reference:
Description:
Brand Nme: Ublox NEO-M8N GPS Module
The under pictures are for reference:
Description:
Brand Nme: Ublox NEO-M8N GPS Module
Receiver Type:72-channel u-blox M8 engine
GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
SBAS L1 C/A: WAAS, EGNOS, MSAS
Galileo-ready E1B/C (NEO-M8N)
Nav. Update Rate1 Single GNSS: up to 18 HZ
Concurrent GNSS: up to 10 Hz
Position Accuracy:2 2.0 m CEP
Acquisition2 Cold Starts: 26 s
Aided Starts: 2 s
Reacquisition: 1.5 s
Sensitivity2 Tracking & Nav: –167 dBm
Cold Starts: –148 dBm
Hot Starts: –156 dBm
Built-In: RTC Crystal Built-In
Anti Jamming Active CW Detection and Removal. Extra
Onboard SAW Band Pass Filter (NEO-M8N/Q)
Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N)
Data-logger For position, velocity, and time (NEO-M8N)
Operating Temperature: –40° C to 85° C
Storage Temperature: –40° C to 85° C (NEO-M8N/Q) –40° C to 105° C (NEO-M8M)
RoHS Compliant (lead-free)
Manufactured and fully tested in ISO/TS 16949 certified production sites
Uses u-blox M8Chips Qualified: according to AEC-Q100
Supply Voltage: 1.65 V to 3.6 V (NEO-M8M) 2.7 V to 3.6 V (NEO-M8N/Q)
Power Consumption:4 23 mA @ 3.0 V (continuous)
5 mA @ 3.0 V Power Save Mode
(1 Hz, GPS mode only)
Backup Supply: 1.4 to 3.6 V
NEO-M8N-0 u-blox M8 Concurrent GNSS LCC Module
TCXO, flash, SAW, LNA,
Timepulse Configurable: 0.25 Hz to 10 MHz
Qualification: according to ISO 16750
Usage For: PX4/PIX4 APM2.6/2.8 Mini APM Built-in Compass
Feastures:
Package Included:
Usage For: PX4/PIX4 APM2.6/2.8 Mini APM Built-in Compass
Feastures:
- Assistance AssistNow GNSS Online
- AssistNow GNSS Offline (up to 35 days)3
- AssistNow Autonomous (up to 6 days)
- OMA SUPL & 3GPP compliant
- Oscillator TCXO (NEO-M8N/Q)
- Crystal (NEO-M8N)
- WIth GPS folding antenna base
- Noise Figure On-chip LNA (NEO-M8M). Extra LNA forLowest Noise Figure (NEO-M8N/Q)
- Noise Figure On-chip LNA (NEO-M8M). Extra LNA forLowest Noise Figure (NEO-M8N/Q)
- Ublox new generation GPS NEO-M8N is very quick to searching signal, of high positioning precision and efficiency.
- This NEO-M8N GPS adopts original imported M8N chip, function module group is optimized, built in electric compass, updating rate has been improved to 10GHZ
- Supported Antennas Active and Passive
- Odometer Travelled Distance
- Support European, Russian GLONASS, Japan , China
- Module supports GPS+Big Dipper+SBAS or GPS+GLONASS+SBAS
Package Included:
1 x NEO-M8N Flight Control GPS
1 x GPS Holder
