Ublox NEO-M8N Flight Controll GPS Module for PX4 PIX APM2.5/2.6 Built-in Compass
GPS+GLONASS Dual Module Mode:
GPS+BeiDou Dual Module Mode:
Description:
Item Name:GPS Module
Power Supply:DC Voltage 2.8V~6.0V,Typical:3.3V or 5.0V
Consumption:Capture 50mA@5V
Receiving Format:GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
Receiving Channel:72 Searching Channel
Receiving Sensitivity:Trace -167dBm
Capture-148dBm
Positioning Time:Cold Start:avg26s
Warm Start:avg25s
Hot Start:avg3s
Level Positioning Precison:2m At Open Wind
Output Frequency:1Hz-10Hz,Default 1Hz
Speed Precison:0.1 m/s (Without Aid)
Acceleration Precison:0.1 m/s (Without Aid)
Dynamic Characteristics:Max Height:18000m
Max Speed:515m/s
Max Acceleration:4G
UART Interface:UART Port:TXDA and RXDA
Support Rate:4800bps to 115200bps,Default 9600dps
Working Temperature:-40â-+85â
Storage Temperature:-40â-+85â
CircleDiameter:45mm
Height:6mm
Weight:10g
Features:
GPS Module,built-in compass
With electronic compass IC HMC5883L
1.25mm spacing between the 6pins patch seat
GPS Connector Definition:
Connector 1:
GND,Earthing
TX,Module data output
RX,Module data intput
VCC,2.8V-6V
Connector 2:
Compass SCL clock pin
Compass SDA clock pin
Pcakage Included:
1xGPS Module
