Ublox NEO-M8N BN-800 GPS Module Support GPS GLONASS BeiDou For Pixhawk APM
Description:
Item Name:GPS Module
Model:BN-800
Power Supply:DC Voltage 2.8V~6.0V,Typical:3.3V or 5.0V
Consumption:Capture 50mA@5V
Receiving Format:GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS
Receiving Channel:72 Searching Channel
Receiving Sensitivity:Trace -167dBm
Capture-148dBm
Positioning Time:Cold Start:avg26s
Warm Start:avg25s
Hot Start:avg3s
Level Positioning Precison:2m At Open Wind
Output Frequency:1Hz-10Hz,Default 1Hz
Speed Precison:0.1 m/s (Without Aid)
Acceleration Precison:0.1 m/s (Without Aid)
Dynamic Characteristics:Max Height:18000m
Max Speed:515m/s
Max Acceleration:4G
UART Interface:UART Port:TXDA and RXDA
Support Rate:4800bps to 115200bps,Default 9600dps
Working Temperature:-40â-+85â
Storage Temperature:-40â-+85â
Weight:5g
Size:35 x 35 x 6mm
Gps Chip parameters:
Receiver type 72-channel u-blox M8 engine
SBAS L1 C/A: WAAS, EGNOS, MSAS
Galileo-ready E1B/C (NEO-M8N)
Nav. update rate1 Single GNSS: up to 18 HZ
Concurrent GNSS: up to 10 Hz
Position accuracy2 2.0 m CEP
Acquisition2 Cold starts: 26 s
Aided starts: 2 s
Reacquisition: 1.5 s
Sensitivity2 Tracking & Nav: –167 dBm
Cold starts: –148 dBm
Hot starts: –156 dBm
Assistance AssistNow GNSS Online
AssistNow GNSS Offline (up to 35 days)3
AssistNow Autonomous (up to 6 days)
OMA SUPL & 3GPP compliant
Oscillator TCXO (NEO-M8N/Q),
Crystal (NEO-M8M)
RTC crystal Built-In
Noise figure On-chip LNA (NEO-M8M). Extra LNA for
lowest noise figure (NEO-M8N/Q)
Anti jamming Active CW detection and removal. Extra
onboard SAW band pass filter (NEO-M8N/Q)
Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N)
Supported antennas Active and passive
Odometer Travelled distance
Data-logger For position, velocity, and time (NEO-M8N)
Operating temp. –40° C to 85° C
Storage temp. –40° C to 85° C (NEO-M8N/Q)
–40° C to 105° C (NEO-M8M)
RoHS compliant (lead-free)
Qualification according to ISO 16750
Manufactured and fully tested in ISO/TS 16949 certified production sites
Uses u-blox M8 chips qualified according to AEC-Q100
Supply voltage 1.65 V to 3.6 V (NEO-M8M)
2.7 V to 3.6 V (NEO-M8N/Q)
Power consumption4 23 mA @ 3.0 V (continuous)
5 mA @ 3.0 V Power Save Mode
(1 Hz, GPS mode only)
Backup Supply 1.4 to 3.6 V
NEO-M8N-0 u-blox M8 Concurrent GNSS LCC Module,
TCXO, flash, SAW, LNA,
Timepulse Configurable 0.25 Hz to 10 MHz
Features:
With U-blox M8
Can simultaneously acquire and track different GNSS (Global Navigation Satellite) system,parallel to receive GPS (QZSS) and GLONASS or BeiDou, or while receiving GLONASS and BeiDou.
Specially adapted to the needs to the highest availability and accuracy of high-performance applications,even if is in the GPS signal poor environment.
Equipped with a built-in intelligent automatic switching function.
With long Offline A-GNSS (GPS and GLONASS) function.
Support GPS + BeiDou
Can run simultaneously GPS + GLONASS or GPS +BeiDou
With GPS antenna
Low power consumption
Fast positioning speed
Search to more number of satellites and high positioning accuracy
Notice:
Cable supports mini APM,if it is used for version 2.6 or 2.8,GPS of Pixhawk is needed to change the cable by yourself.
Can not use for flight control with SCM,but it is also suitable for Open source flight controller.
GPS Program Set up documents and instructions:
Package Included:
1xBN-800 GPS Module
1x Cable
