UBLOX NEO-M8N-001 BD GPS Module With Antenna For APM MWC Flight Controller
Description:
- Use U-BLox NEO-M8N-0-01 GPS module
- With ceramic antenna, very strong signal
- EEPROM power save function
- With backup battery
- With LED indicator lamp
- Antenna size: 25*25mm
- Module size: 25*35mm
- Install hole: 3mm
- Power supply: 3-5V
- Default baud rate: 9600
Previous: 3D Printed Single-Axis Pitch Servo Gimbal for Mobius 808#16 Camera
Next: QAV250 Upgrade Quadcopter Part Devices Mounting Bracket
Features:
UBLOX GPS Module APM2.5 NEO-M8N Flight Controller with active antenna
72-channel u-blox M8 engine
Ceramic Antenna
Input Voltage 3V -> 5V
Position accuracy 2.0 m CEP
Cold starts: 26 s
The NEO-M8 series of standalone concurrent GNSS modules is built on the exceptional performance of the u-blox M8 GNSS (GPS, GLONASS, BeiDou, QZSS, SBAS and Galileo-ready1) engine in the industry proven NEO form factor.
The NEO-M8 series provides high sensitivity and minimal acquisition times while maintaining low system power. The NEO-M8M is optimized for cost sensitive applications, while NEO-M8N/M8Q provides best performance and easier RF integration.
The NEO form factor allows easy migration from previous NEO generations. Sophisticated RF-architecture and interference suppression ensure maximum performance even in GNSS-hostile environments.
The NEO-M8 series combines a high level of robustness and integration capability with flexible connectivity options. The future-proof NEO-M8N includes an internal Flash that allows simple firmware upgrades for supporting additional GNSS systems. This makes NEO-M8 perfectly suited to industrial and automotive applications.
Datasheet
Concurrent reception of GPS/QZSS, GLONASS, BeiDou
Industry leading –167 dBm navigation sensitivity
Product variants to meet performance and cost requirement
Combines low power consumption and high sensitivity
Simple integration with u-blox wireless modules
Backward compatible with NEO-7, NEO-6 and NEO-5 family
72-channel u-blox M8 engine GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 SBAS L1 C/A: WAAS, EGNOS, MSAS Galileo-ready E1B/C (NEO-M8N)
Position accuracy 2.0 m CEP
Acquisition
Cold starts: 26 s
Aided starts: 2 s
Reacquisition: 1.5 s
Sensitivity
Tracking & Nav: –167 dBm
Cold starts: –148 dBm
Hot starts: –156 dBm
Assistance AssistNow GNSS Online
AssistNow GNSS Offline (up to 35 days)
AssistNow Autonomous (up to 6 days)
OMA SUPL & 3GPP compliant
Oscillator TCXO
RTC crystal Built-In
Anti jamming Active CW detection and removal.
Extra onboard SAW band pass filter
Memory Flash
Supported antennas Active and passive
Odometer Travelled distance
Data-logger For position, velocity, and time
Packing Included:
1× UBLOX NEO-M8N-001
