Description:
Item Name: UBLOX LEA-6H GPS Module
Item No.: LEA-6H
Power supply: 2.7V- 3.6V
Power consumption: Continuous: 121 mW
Power Save Mode:5 36 mW
Backup power:1.4 V – 3.6 V, 22 μA
Antenna power:External or internal VCC_RF
Supported antennas:Active and passive
Operating temp.: -20°C ~ 60°C
interfaces :UART,USB,DDC
Features:
• u-blox 6 position engine:
o Navigate down to –162 dBm and –148 dBm coldstart
o Faster acquisition with AssistNow Autonomous
o Configurable power management
o Hybrid GPS/SBAS engine (WAAS, EGNOS, MSAS)
o Anti-jamming technology
• Simple integration with u-blox wireless modules
• A-GPS: AssistNow Online and AssistNow Offline services, OMA
SUPL compliant
• Backward compatible (hardware and firmware); easy migration
from LEA-5 or LEA-4 families
• LCC package for reliable and cost effective manufacturing
• Compatible with u-blox GPS Solution for Android
• Based on GNSS chips qualified according to AEC-Q100
• Manufactured in ISO/TS 16949 certified production sites
• Qualified according to ISO 16750
Highlights:
• Multi-constellation variants:
o GPS, Galileo ready (LEA-6H)
• Optimized mode for low power and maximum sensitivity
• UART, USB and DDC (I2C compliant) interfaces
• Integrated antenna supervisor
Package included :
1 x 6H GPS module
1 x wires set
