TX500 5.8G 500mW Wireless Video Transmission Sender Transmitter
Feature:
With the original 2dB small flat antenna, which make 1/3 faster distance than normal antennas.
The measured surface unobstructed distance can up to 2~3km, and air distance will be far more than the distance from the ground.
The built in Mic is a humanized design for user.TX500 come with 5PIN universal connection line(+5V out,Audio In,Video In,+12V our ,Ground),
people can easily connect it to their devices without requiring a separate wire.
Description:
Item Name:TX500 transmitter
Video Format: PAL/NTSC
Antenna Gain: 2dB
Size:68mm*68mm*25mm
Wight:50g
Working frequency:
CH1: 5705
CH2: 5685
CH3: 5665
CH4: 5645
CH5: 5885
CH6: 5905
CH7: 5925
CH8: 5945
Package includ:
1 x TX500 Transmitter
1 x Antenna
1 x Power Cable
1 x Video Output
