TowerPro MG996R Metal Gear Digital Torque Servos With Cross Arm
Description:
The MG996R is an upgraded version of the famous T-Pro MG995 series. It has a completely new redesigned PCB and IC control system to provide more accuracy. Its internal gearing and motor are also upgraded to improve dead bandwidth and centering. The MG996R servo is far more accurate and safe to use in aircraft which require precise servo movements and perfect centering. Super strong and beefy with very little signs of flexing.
Servo wires are very thick compared to most standard servos to handle the peak currents required for high torque servos. Includes a very nice set of rubber bushings with brass inserts to protect the servos from vibration. The MG996R servos are precise and relatively quiet and the claims of its' performance are accurate. Very fast, very high torque on 6V for 1/8 scale cars, trucks, truggy and buggy! For this price this is probably the best servo for robotic use as well.
Model MG996R Dimensions 40.7*19.7*42.9mm Weight 55g Unload Speed 4.8V 0.17sec/60° 6V 0.14 sec/60° Torque 4.8V 9.4kg/cm 6V 11kg/cm Working Voltage 3.0-7.2V Operating current 100mA Deadband 5μs Wire length 30cm
Usage:1/10 and 1/8 scale sports car/off-road vehicles, trucks, monster trucks, climbing car, biped robot, robot/Remote Control Boat, for 50 -90 grade methanol fixed-wing aircraft as well as fixed-wing aircraft 26cc-50cc gasoline model.
Package included:
1x Servo with arms and screws
