Description:
Brand name: TINSLY
Item name: TSL-2307
Configuration: 12N14P
Stator diamter: 23mm
Stator length: 7mm
Shaft diameter: 4mm (Hollow)
Motor (dimension(Dia.*Len)): Φ26.7*30.5mm
Rotor: N52H arc magnets
Bearings: NSK
Base casing: Al 7075
Wire AWG: 20AWG
Weight(g): 35
KV: 2650kv
Idle current(10)@10V(A): 2.8
No.of Cells(Lipo): 4~5S
Max continuous (power(W)15S): 1000
Internal resistance: 29mΩ
Max current(30S): 48A
Max.effciency current: (4-8A)>81%
Features:
1. NSK high-efficiency bearings
2. 0.15mm silicon steel laminations
3. N52H arc magnets
4. Al 7075 CNC
5. The weight is 34g only
Package included:
1 x TSL2307 motor
1 x M5 aluminum lock nut
4 x M3x6 screws
4 x M3x8 screws
