Tarot T4-3D FPV 3 Axis Brushless Gimbal For Gopro Hero 3 Hero 4
Description:
Description:
-Tarot T4-3D Brushless Gimbal integrates the high-end technology of all the Tarot series products and designs for GOPRO HERO3/HERO4 and the same size and weight of the camera.
-Adopte the combination of aluminum and engineering plastics
-Extreme lightweight and the strongest stability
-Lock camera accurately and maitain stability even in harsh environments
-Output delicate industrial-grade picture of the extreme experience
-Adopts advance attitude arithmetic:BLDC gimbal dedicated brushless motor decoupled EKF
-Built-in independent IMU to control gimbal's attitude precisely.
-Integrated gimbal and servo drive module
-Support two kinds of working mode:PF and FPV.
-All of the power supply and signal lines skillfully embedded in yuntai structure
-Speed of the pitch axis is controlable.
In a word,it's the best choice of professional film and television camera crews and FPV fans.
Feature:
-Support PC interface Settings
-Mode:PF and FPV
-Built-in independent IMU module
-Gimbal dedicated servo driver module
-AV output interface
-Support the wide range input voltage
-Support the general receivers/S-Bus receivers/DSM receivers
-Support the type of cameras:GOPRO HERO3/HERO4 and the same size and weight of the camera.
-Input:2S-6S LiPo battery(7.4V-22.2V)
-Control accuracy:±0.02°
-The largest controllable speed:±200°/s(Titl)
-Control range:-120°to 15°(Titl)
-120°to 125°(Pan)
-25°to 25°(Roll)
-Working current:30mA(@25V) 50mA(@12V)
-Locked-rotor current:350mA(@25V) 700mA(@12V)
-Working Temperature:-20°C ~50°C
-Weight:178g
-Size:99mm*88.5mm*105.6mm
Requirements of the adjustable parameter software installation:
Windows XP;Windows VISTA;Windows 7;Windows 8(32 or 64 bit)
Package Include:
1 x T4-3D Brushless gimbal
1 x main gimbal control module
1 x cable linking gimbal and control module
1 x 5V output,a receiver and video line
1 x USB module
1 x flight control cable
1 x packing box
