Tarot MT2204-1550KV Self-lock Brushless Motor Silvery Black Hat CW CCW TL400H1 TL400H2
Description:
Brand Name:Tarot
Model:TL400H1(Silvery CW);
TL400H2(Black CCW)
Stator Diameter:22mm
Stator Height:4mm
Power Supply:3S
Propeller Install Diameter:5mm
Paddle Size:6-inch 3-Leaf Propeller
Interphase Resistance:≤4mΩ
No-load Current:0.4A-0.8A
Stator End Thickness:4.0
Stator End Quantity:12
Motor Pole Number:14
Rotate Speed:1550KV ± 5%
Motor Outer Diameter:28mm
Axis Diameter:2mm
Motor Length:39mm
Motor Weight:24.5g
Feature:
- Tarot 2204-1500KV self-lock brushless motor is suitable for 280/300 multicopter.Tarot optimizes 1806 brushless motor.Its center of gravity is more lower and meets the requirement of multicopter design.
- Tarot 2204-1500KV self-lock brushless motor uses 0.20 mm ultra-thin high efficiency silicon steel sheet.Using thin silicon steel sheet can make the motor has the characteristics of low calorific value and high efficiency.
- The pedestal of propellers use the one-piece machining with the motor cover.One-piece machining screws can make the propellers be installed directly and the concentricity can get the best guarantee.
- Motor cover with high efficient active pad design can obtain lower temperature which means higher work efficiency.
- Tarot 2204-1500KV self-lock brushless motor has the dynamic balance performance.Each motor must pass a high-precision dynamic balancing tester before the shipment to ensure the stability of the machine during operation .
- The installation size of motor's base is 16mm/19mm and it is compatible with the rack installation of mainstream on the market at present and retains the appearance and consistency of traditional motor.High dangling design can protect the coil.
Package included:
1 x MT2204-1550KV Motor
1 x Round Head Hex Socket Screw(M3*5mm)
