Tarot MT1104 4000KV Brushless Motor 3s For Multirotor
Specification:
Brand Name: Tarot
Item No: MT1104
Item Name: MT1104 4000KV Brushless Motor
Height: 17.5 mm
Axial Diameter: 1.5 mm
Outer diameter: 14 mm
Installation propeller diameter: 5mm
Stator diameter: 11mm
Stator end thickness: 4.0
Stator end: 9
Weight: 5.3 g
Motor poles: 12
RPM/V: 4000KV±5%
Voltage: 3S
Battery: 3S lithium polymer
Mounting pattern: Φ14×12.5mm
Package Included:
1 X MT1104 brushless motor (Φ14 × 12.5mm)
Brand Name: Tarot
Item No: MT1104
Item Name: MT1104 4000KV Brushless Motor
Height: 17.5 mm
Axial Diameter: 1.5 mm
Outer diameter: 14 mm
Installation propeller diameter: 5mm
Stator diameter: 11mm
Stator end thickness: 4.0
Stator end: 9
Weight: 5.3 g
Motor poles: 12
RPM/V: 4000KV±5%
Voltage: 3S
Battery: 3S lithium polymer
Mounting pattern: Φ14×12.5mm
Features:
1.Tarot MT1104-4000KV brushless motor suitable for 120/130 high-end configuration of multirotor.The proposed weight of quadcopter control within 180g (single pull up to 120 grams). MT1104 brushless motor extremely low center of gravity, using 0.20mm ultra-thin high-efficiency silicon steel (primary propeller shaft folder structure) so that it can get the best concentricity guaranteed. A highly efficient bulk active pad designed to achieve lower operating temperature means higher productivity.
2.MT2204 brushless motor with excellent balancing performance, base mounting holes motor 9MM, compatible with mainstream rack-mount on the market today, retain the appearance and consistency of conventional motor.In addition,high vacant protect the coil.
Package Included:
1 X MT1104 brushless motor (Φ14 × 12.5mm)
2 X M2 × 6mm round head sleeve screws
2 X M2 × 4mm cup head hexagon screws
A pair of 3.0x3.0 inch propellers
