Tarot Mini 200mm Combo 4-Axis RC Quadcopter BNF TL200B







Description:
Brand Name: Tarot
Item Name: Combo RC quadcopter
Item NO.: TL200B
Wheelbase: 200mm
Empty Rack Height / Assembly Height : 30mm / 65mm
Empty Frame Length / Assembly Length : 168mm / 185mm
Empty Frame Width / Assembly Width : 168mm / 168mm

Specification:
Tarot TL300M Camera Lens 2.8mm Camera Angle 120° Definition 600TV Lines (HD) Effective pixels PAL = 720 (H) × 576 (V) / NTSC = 720 (H) × 487 (V) Video system NTSC / PAL Sensitive chip 1/3 inch HD Color CMOS Video Output 1.0Vp-p / 75Ω Minimum illumination 0.008Lux (ultra low-light) Power consumption 40MA ± 10% Operating voltage DC5-15V ± 10% Synchronization System Internal Synchronization SNR >50dB An electronic shutter (N) 1 / 60-1 / 10000s, (P) 1 / 50-1 / 10000s Working temperature 0 degree ~ 45 degree Weight 15g Size 21*26*30 ± 3mm Tarot TL300N Image Receiver Weight 10.9 G (without antenna) Dimension 28 x 46 x 40 mm Working frequency 5645-5945 MHZ Channel 4 bands / 32 channels Channel selection 5-DIP switch Receiving Sensitivity -85 dbm Input Voltage DC 7-26V (2-6S) Antenna Adaptor RP SMA 50Ω Working Temperature -10 ~ 60 degrees Frequency FM/PLL Output 2.5mm 4 pins AV output Power input 3.5mm (exterior) 1.3 mm (interior) DC Tarot TL300N Transmitter module Weight 8.3G (without antenna) Dimension 21 x 33 x 7.5 mm Working Frequency 5645-5945MHz Channel 4 bands / 32 channel Channel selection 5-DIP switch Output Power 27.5 dbm (600mw) Input Voltage DC 7-26V (2-6S) Output Voltage 5V 1A Antenna Adaptor RP SMA 50Ω Working Temperature -10 ~ 60 degrees Frequency FM Transmission frequency 5800MHZ Gain 2.0dBi-2.5dBi Note Bobby <1.5 Directivity Omnidirectional Horizontal beam width 45 ° Vertical beam width 45 ° Impedance 50Ω Antenna adapter RP-SMA Male Polarization circular polarization Tarot TL300H Motor Power Supply 2-3S Prop Diameter 5mm Max Thrust 460g Interphase Resistance ≤4mΩ Stator Diameter 18mm No-load Current 0.4A-0.7A Stator End Thickness 6.0 Stator End Quantity 12 Motor Pole Number 14 Rotate Speed 2280KV ± 5% Motor Outer Diameter 23mm Axis Diameter 2mm Motor Length 26.5mm Motor Weight 18g Tarot TL300E Propeller Spec. 5 inch 3-leaf  Tarot TL300G ESC Spec. 12A(with BEC) Tarot TL300D Flight controller Spec. CC3D Openpilot
Features:
- Super lightweight,allows the camera,battery,ESC, image transmission and antenna to be plugged directly on the frame or soldered on the PCB board,much less wiring,easy to install.
- Using recommended 15c/11.1v1000mah battery,can enjoy 9 min flight.
- Compatible with 2.4G/5.8G transmitter,enjoy the fun of DIY.
- Equipped with Tarot series camera,antenna,motor,ESC,image transmission,propeller and flight controller,you can assemble your own characteristic quadcopter.

Note:Not included the battery,remote controller and receiver module.

Related Parts Sold In Our Store:(Not included)
Recommended battery:15C/11.1V/1000MAH, Size<(70 X 32 X 20mm)
The similar battery sold in our store,
Recommended TFR6 receiver module,
Recommended transmitter: 2.4G 7CH,
Recommended 5.8G 32CH monitor,
The empty frame TL200A,

Package Included:
1x TL200A frame
1x TL300M camera
1x TL300N image transmission & receiver module
1x TL300D CC3D Openpilot flight controller
1 set x TL300K 5.8g antenna
1 set x TL300E 5 inch 3-leaf propeller
1 set x TL300G 12A ESC
1 set x TL300H 1860-2280KV brushless motor
