Description:
Brand: Tarot
Model: TL45110-06
Weight: 100g
Item Name: Tarot 450 FBL Flybarless Rotor Head Sliver
450 PRO New One piece FL Main Rotor Housing Set TL45117 x 1
Integrated spindle demper x 2
Cup head screw (M2x9.5mm) x1
Cup head screw (M2x6.0mm) x3
Cup head screw (M2x8.0mm) x2
Enhanced hex nut (M2) x 1
Rotor head stopper x1
Radius rod x 2
Bearings (1.5x4x2mm) x 4
Frange bearings (2x5x6x2.3mm) x 4
450FL metal control arm x 2 (TL45113)
Socket button head screw (0 # x 4mm) x 4
Metal rotor holder x 2 (TL48013)
Bearing(Φ4.0xΦ9x3.0mm) x 2
Thrust bearing x. 2 (Φ4.0xΦ9x4.0mm)
Washers x 2 (Φ4xΦ6.5x0.5mm)
Bearing x of 2 (Φ4.0xΦ9x4.0mm)
Washers x 2 (Φ2.5xΦ4.5x0.3mm)
12.9 M2.5 * 15MM cup of head SHCS x 2
Cup head screws x 2 (M3 x 15MM)
M3 slip nut x 2
The 450 DFC new shanle shaft TL48009 (Φ4.0x54.0mm) x 1
450DFC main rotor holder arm TL48014 x 2
12.9 M2 * 5MM Cup head x 2
12.9 M2 * 9MM Cup head x 2
Features:
1.6061-T6 aluminum with CNC processed
2.Suitable for TAROT/ T-REX 450 series models
3.New split main grips TL48013 use slip nut limit hole,locking without using a wrench,easy-to-use.
4.The split extended arm (TL48014) speical design to provide crush zone for main grip.
5.The new design of main grip will seat the thrust bearing insind,reducing the virtual potential swing.
6.Large size bearings can withstand more tension,in order to adapt to the current models of large power requirements.
7.The new M2.5 linkage bal use stepped threaded design is bring better contact surface and avoid thread stress point.
8.New split main rotor holder TL48013 applies to all rotor hub width 27MM to upgrade,the package comes with TL48009.
9.New spindle using 480 size design
10.Effective thread depth of the spindle bore 8MM, in order to avoid the impact.
11.Main Rotor Housing New spindle lock design, effective to hold fast to the spindle to prevent the holder swing.
12.Flybarless spindle holder to use ultra-low CGdesign enables the main rotor disk close to the CG.
13.This product can be used length 32.8MM 450FL rod TL2639 (optional).
14.It will be broken easier than main grip from serious impact, thus save your main grip.
Package Includes:
1 x Sliver Main Rotor Set
