Thrust bearings installed need to note that the, IN outside diameter of the retaining ring be installed close to the the Vanda position, so you can
Effectively smooth pass Rally. Thrust bearing steel copper concave inwardly, in order to prevent lubricating oil thrown.
Description:
6061-T6 CNC integrated molding process applies to all associated width the 27MM of 450DFC modified,comes with matching [450 DFC affine horizontal axis TL48009].
The new design of large-size bearings folder will seat thrust bearing center,indirect extension of the the bearing side swing arm to reduce the virtual potential swing.
Large size bearings can withstand stronger pull adapt to the current mainstream models of large power requirements of 450DFC main rotor holder to extend the arm [TL48012] wearing design, this design is a significant reduction in use intothis.
The big paddle folder Anti-slip-Nut Nut limit hole without using a wrench, easy-to-use locking. Main Rotor Holder the top increase humane adjust the main rotor design, scale line clamp base level, easy pitch adjustment to 0 degrees.
New anti-shot horizontal axis the overall the tensile design with 480 specifications.
Screw locking horizontal axis 12.9 M2.5 diameter, this design effectively reduce the shot paddle probability.
The large bearing Moderator blade grips seat group the overall tensile designed 480
Related products:
The Seat 450 DFC main blade grips TL48011 TL48012 and TL48010 combination. Need to match the 450 DFC
Main Rotor Housing Set TL45163 and 450DFC main rotor rod set TL45165 is the whole to group 450DFC rotor head.
Package Includes:
The metal bearing Moderator rotor holder × 2
Bearing × of 2 (Φ4.0xΦ8x3.0mm)
Thrust bearing ×. 2 (Φ4.0xΦ9x4.0mm)
Washers × 2 (Φ4xΦ6.5x0.5mm)
Bearing × of 2 (Φ4.0xΦ9x4.0mm)
Washers × 2 (Φ2.5xΦ4.5x0.3mm)
12.9 M2.5 * 15MM cup of head SHCS × 2
Cup head Hexagon collar screw x 2 (M3 × 15MM)
M3 slip nut × 2
The 450 DFC Anti shot horizontal axis TL48009 (Φ4.0x54.0mm) × 1
450DFC main rotor holder to extend the arm TL48012 × 2
12.9 M2.5 * 4MM Cup head SHCS × 2
