Tarot 4114/320KV Multi-copter Brushless Motor TL100B08
Description:
Tarot 4114/320KV Brushless Motor adopting CNC process with smooth surface and well balance is specially designed for high efficiency multi-copter. The brushless Tarot motor consists of brand-new turbofan cover, which provide good heat dissipation effect, neodymium iron boron rotor and epoxy resin stator. Tarot 4114/320KV Brushless Motor is well-balanced from factory, which solves vibration issue a lot. Motor shaft is alloy steel applied.Motor upper and lower cover are special bearing applied, which has advantages such as low frictional torque, low power consumption, impact resistance, strong radial support.
Model Tarot 4114/320KV Full Length of Motor 37.0mm Diameter of Motor 46.00mm Configuration 24N 22P Length of Motor 32.0mm Idle Current @22.2V 0.5 Amps Weight of Motor 148g Internal resistance 126 mΩ Diameter of Stator 41.0mm Diameter of shaft ￠4.0 mm
Test data:
Floating Current Voltage(V) Current(A) 10 0.4 22.2 0.5 25.2 0.6
Thrust Test Propeller DJI----15x5 Thrust(kg) Voltage(V) Current(A) RPM g/W W/Kg 1.0 25 5.2 4370 7.69 130.0 1.5 25 7.4 5045 8.11 123.33 2.0 25 11.1 5755 7.21 138.75 2.5 25 15.1 6311 6.62 151.00
Max. Thrust Test Propeller DJI----15x5 Thrust Voltage Current RPM g/W W/Kg 2.15 22.2 14.5 5979 6.68 149.72 2.65 25.2 16.8 6655 6.26 159.76
Package included:
1x Tarot 4114/320KV Motor
1x Tarot Motor set
