Tarot 4006/620KV Multi-axis Brushless Motor TL68P02
Description:
1.Product Name:Tarot 4006/620KV Multi-axis Brushless Motor TL68P02
2.Product description :
Tarot 4006/620 kv efficient multiple brushless motor designed for four axis and six axis rotor aircraft /hexacopter,
using the high precision CNC processing production, shaped flat table is smooth
and flawless, excellent balance to the new design of efficient turbofan cover, provide a powerful cooling airflow,
the rotor using high ndfeb magnetic material and fine.
Product parameters :
Peripheral motor diameter : 46MM
Stator diameter : 40.6M
Stator Thickness : 6MM
Stator : 24 slots
Motor Poles : 22P
Diameter : 0.23MM
Gear shaft mounting diameter : ¢ 4MM
Motor height : 22.0MM
Motor shaft Full length : 30.50MM
Per volt Speed : 620 RPM / Volt
Motor Weight : 82G
Motor resistance : 126 mΩ
14.8V No Load Current : 0.8A
14.8 Load Current : 14A
4006 brushless motor installation specifications : 27.7MM equilateral triangle
Propeller installation specifications : the main hole diameter 4mm, 3mm diameter side hole center distance 12mm
Specifications:
1X 4006/620KV brushless motor 82G
3X M3 × 6MM cup head screws
2X M3 × 8MM round head screws
1X Metal rotor mounting piece 2.5G
