Awesome accessory for yor RC toys: T690AC T-Plug Color LCD Touch-Screen 90W Balance Charger
Specifications:
Input Voltage: 11-18VDC or 100-240VAC
Charging Current/Power: 0.1-6.0A/90W max
Discharge Current/Power: 0.1-2.0A, 10W max
Balance Current: 300mA max
Balance Tolerance: +/- 0.01v
Cell Count: 1-6 Cells LiPo/LiFe/Li-ion, 1-18 Cells NiMH/NiCd, 2-24V Pb (Lead Acid)
Discharge: 2.0-4.2V/Cell LiPo/LiFe/Li-ion
Color: silver&black
Size: 185mm*140mm*55mm
Package size: 212mm*186mm*65mm
Net weight: 651g
Package weight: about 780g
Features:
1.The 690AC-Pro boasts a sleek housing with fully sealed buttons to kee dirt out, and packs a full 6.0 Amps of charging power at 90W to make a quick job of charging up your packs. An easy-to-navigate menu and a price that doesn't break the bank round out the 690AC-Pro.
2.AC/DC power means you have the option of plugging it into a wall or power it from a battery or power supply with the included alligator-clip harness.
3.Charges LiPo, Li-Ion, LiFe, NiMH, NiCd, and Lead-Acid batteries
4.Powerful, built in 90W power supply
5.Easy to use and navigate menu
6.Optimized operating software regulates current and eliminates charging errors
7.Real time display shows current, capacity, temperature (requires temperature probe, not included) & time
I8.ndividual cell balancer for accurate balancing to +/- 0.01V per cell
9.Charge/Balance Charge/Fast Charge/Storage/Discharge
Note:
1.Do not use input voltage AC100~240V and DC 14V / 16A simultaneously when charging or discharging.
2.Do not charge for 2 or more groups batteries simultaneously.
3.Both of these incorrect opperating easily lead to short circuit of charger.
Package included:
1 x T690AC-Pro AC/DC Charger
1 x T-Plug, Futaba/JR, Glow Igniter, JST and Alligator Clip charge leads
1 x Power lead with alligator clips
1 x Balance Board with extension for 1S-6S LiPo batteries
