Main Features of Motor:
- 4 poles 12 slots high torque motor design
- With high temperature resistant coil
- High-quality aluminum alloy, for maximum energy conversion
- Precision balanced rotor, smoothness for best reliability and maximum RPM
- High purity copper windings for maximizing efficiency
- Suitable for 1 / 14, 1 / 12 brushless RC cars
Main Features of ESC:
- Supports 2 - 3S, BEC input and 5.8V 3A linear
- With excellent start-up, acceleration and linearity features
- Multiple protection features design: low voltage cut-off protection, over-heat protection and throttle signal loss protection
- Internal timing can be changed easily to make the ESC suitable for various of motors
- Plenty of programmable items, suitable for 1 / 14, 1 / 12 brushless RC cars
Specifications of Motor:
KV: 3930KV
Max current: 60A
Max watts: 800W
Dimension ( Included cable ): 14 x 2.5 x 2.5cm
Weight: 97g
Specifications of ESC:
Constant current: 35A
Dimension: 30 x 3.5 x 2.5cm
- With high temperature resistant coil
- High-quality aluminum alloy, for maximum energy conversion
- Precision balanced rotor, smoothness for best reliability and maximum RPM
- High purity copper windings for maximizing efficiency
- Suitable for 1 / 14, 1 / 12 brushless RC cars
Main Features of ESC:
- Supports 2 - 3S, BEC input and 5.8V 3A linear
- With excellent start-up, acceleration and linearity features
- Multiple protection features design: low voltage cut-off protection, over-heat protection and throttle signal loss protection
- Internal timing can be changed easily to make the ESC suitable for various of motors
- Plenty of programmable items, suitable for 1 / 14, 1 / 12 brushless RC cars
Specifications of Motor:
KV: 3930KV
Max current: 60A
Max watts: 800W
Dimension ( Included cable ): 14 x 2.5 x 2.5cm
Weight: 97g
Specifications of ESC:
Constant current: 35A
Dimension: 30 x 3.5 x 2.5cm
Specifications
General |
Type: ESC + Motor Set |
|---|---|
Dimension and Weight |
Package weight: 0.172 kg
Package size (L x W x H): 8.00 x 6.50 x 5.00 cm / 3.15 x 2.56 x 1.97 inches |
Package Contents |
Package Contents: 1 x Motor, 1 x ESC, 1 x English Manual |
