Super Mini Light AIO 5.8G 48CH 25mW VTX 520TVL 1/4 Cmos FPV Camera PAL/NTSC for QX90 QX95
Specification:
Item name: AIO FPV VTX Camera
Output power: 25mW
Camera resolution: 520TVL
Camera Lens: M7
Frequency Band: 5362-5945MHZ
Channel Customer: 48
Modulation Type: FM
Channel SEL: Touch Switch
Channel Indicate: CH1-CH8 Channel indicate with 8LEDS and A-F frequency groups indicate with 6LEDS
Transmit Power: 13+/-1dBm
frequency Control: PLL
ALL Harmonic: Max-50dBm
Frequency Stability: +/-100KHz(Typ)
Frequency Precision: +/-200KHz(Typ)
Channel Carrier error: 1dB
Antenna Port: 50
Input Format: NTSC/PAL
Sensor: PAL:720x540/ NTSC:640x480 1/4
Lens Angel: H:120 °/ V:100 °
Base-band interface: (P1.27*2)
Power Consumption: 200~215MA@5V DCIN
Supply Voltage: 3.3-5.5V
Operating Temperature: -10 °~+60 °
Profile Dimension: 14.5mmX12.2mm+14.5mmX12mm
Weight: 5g
Size: 40x15mm
Features:
Support touch switch select channel frequency group.
Support NTSC/PAL switch,support vertical inverted image switch.
8LED display channel and 6LED display frequency group information. LED display NTSC/PAL and FLIP information.
Wide lens angle.
Omnidirectional Clover ANT.
Miniature and light weight design.
Package Included:
1 X AIO FPV Camera
