Sunrise Cicada 30A Blheli_S BB2 2-6S Opto Brushless ESC Support Oneshot125 Multishot for FPV Racer
![](/uploads/modules/catalog/img/15000/1477613953_98_sunrise-cicada-30a-blheli-s-bb2-2-6s-opto-brushless-esc-support-oneshot125-multishot-for-fpv-racer.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/51/81/96f016fd-23f2-4f71-b3aa-c924f6b0a78c.jpg)
![](http://img.banggood.com/images/oaupload/banggood/images/51/81/21f465f5-ef0c-4fd4-9887-1f2667fcdf14.jpg)
Specification:
Brand Name: Sunrise
Model: Cicada 30A
Input Voltage: 2-6S
Con.Current:30A
Peak Current(10s):35A
BEC:NO
Programming :YES
Weight:15.8g
Size(PCB):35x19mm
Features:
-Run on BLHeli-S firmware that is designed for superior performance in multirotors
-Use hardware generated motor pwm for smooth throttle response and silent operation
-All codes use damped light mode
-Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling
-Support features to prevent sync loss, with tuneable parameters that can make the code run well even in the most demanding situations
-Support regular 1-2ms pulse width input, as well as Oneshot125 (125-250us), Oneshot42 (41.7-83.3us) and Multishot (5-25us)
-The input signal is automatically detected by the ESC upon power up
-Also support a beacon function for finding lost aircraft, the ESC will start beeping after a given time of zero throttle.
Package Included:
1x Sunrise 30A ESC
1x Manual
