Sunnysky X2212 KV2450 High Efficient Brushless Motor For RC Model
Description:
Brand Name: Sunngsky
Item Name: X2212 KV2450 motor
Stator Diamteter: 22mm
Stator Thickness: 12mm
NO. of Stator Arms: 12
NO. of Stator Poles: 10
No-Load Current(A/10V):1.6A
Motor Resistance: 32mΩ
Max Continuous Current: 40A/30S
Max Continuous Power:450W
Weight: 57g
Outside Diameter: 27.5mm
Shaft Diameter: 3.175mm
Body Length: 30mm
Overall Shaft Length: 32mm
Max Lipo Cell: 2-3S
Recommended ESC: 40A
Recommended Prop: APC6040
Suitable Aerobatic: 550g(3S,6040)
Testing Data:
Prop Volts Amps Thrust(g) Watts(W) Efficiency Temperature (inch) (V) (A) (g/W) APC6040 11.1 2.2 100 24.42 4.095004095 50° 4.6 200 51.06 3.916960439 7.2 300 79.92 3.753753754 10.8 400 119.88 3.336670003 14.2 500 157.62 3.172186271 18.3 600 203.13 2.953773446 22.4 700 248.64 2.815315315 28.5 880 316.35 2.781729098
Package Included:
1x Sunnysky X2212 KV2450 motor
