Sunnysky X2208 2600KV 1260KV 1100KV Brushless Motor For RC Model
Testing Data of KV1100:
Testing Data of KV1260:
Testing Data of KV2600:
Description:
Brand Name: Sunnysky
Item Name: X2208 brushless motor
KV: 1100KV,1260KV,2600KV(optional)
Specifications:
1100KV 1260KV 2600KV Stator Diameter 22mm 22mm 22mm Stator Thickness 8mm 8mm 8mm No. of Stator Arms 12 12 12 No.of Stator Poles 14 14 14 Motor KV 1100 1260 2600 No-Load Current(A/10V) 0.3A 0.4A 1.2A Motor Resistance 191mΩ 122mΩ 34mΩ Max Continuous Current 14A/15S 15A/30S 30A/15S Max Continuous Power 205W 168W 330W Weight 46g 46g 46g Outside Diameter 27.5mm 27.5mm 27.5mm Shaft Diameter 3.175mm 3.175mm 3.175mm Body Length 25mm 25mm 25mm Overall Shaft Length 27.2mm 27.2mm 27.2mm Max Lipo Cell 2-4S 2-4S 2-3S ESC 18A 18A 40A Recommended Prop(inch) APC9047
APC8038
GWS8043
GWS9047
GWS9050 APC8038
APC9047
GWS8043
GWS8040
GWS9050
5030
5040
APC6040 Trainer 440g (3-4S 9047/9050/8043) 500g(3S 8038/8043/8040) Aerobatic 400g (3-4S 9047/9050/8043) 420g(3S 9047/9050) 450g(3S 5040/6030/6040) 3D Airplane 350g (3S 9047/9050) 350g(3S 9047/9050)
Package Included:
1x Sunnysky X2208 brushless motor
