SunnySky X2208 1500KV Brushless Motor For Fixed-Wing Aircraft - 16.19 €

SunnySky X2208 1500KV Brushless Motor For Fixed-Wing Aircraft
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

SunnySky X2208 1500KV Brushless Motor For Fixed-Wing Aircraft

Description:

Model X2208 1500KV                            Configuration 12N14P Stator Diameter 22mm STator Length 8mm Shaft Diameter 3mm Motor Dimension Φ27.5×26mm Weight 44g Idle current@10v 0.7A Battery support 2-3S Max Continuous current (180S) 15A Max Continuous Power (180S) 150W Max. efficiency current(5-12A) >78% Internal resistance 85mΩ
Testing Data

Propeller (in) Volts (v) Amps(A) Thrust (G) Rpm/min Power(W) G/W 8043 11.1 13.2 820 10600 146.5 5.6 8043 10.8 12.6 800 10500 136.08 5.88 8043 10 11.3 760 9920 113 6.72 9050 8 11 580 7540 88 6.6 9050 7.4 9.8 500 7140 72.52 6.89 9050 6.8 8.8 480 6760 59.84 8.02 1047 8 14.5 700 6260 116 6.03 1047 7.4 13.1 630 5970 96.94 6.5 1047 6.8 11.7 540 5680 79.56 6.78
Package included:
1 x SunnySky X2208 KV1500 Brushless Motor
