Sunnysky R1806 2380KV 2-4S Outrunner Brushless Motor for FPV Racer - 11.99 €

Sunnysky R1806 2380KV 2-4S Outrunner Brushless Motor for FPV Racer
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Sunnysky R1806 2380KV 2-4S Outrunner Brushless Motor for FPV Racer










MOTOR OUTLINE DROWNING




MOTOR TEST TABLE


Specification:
Brand Name: Sunnysky
Model: R1806
Item Name: R1806 2380KV 2-4S Brushless Motor
KV: 2380
Stator Diameter: 18mm
Stator Thickness: 6mm
No. of Stator Arms: 12
No. of stator Poles: 14
No-load Current: 0.8A@10V
Motor Resistance: 90mΩ
Max. Continuous Current: 27A/15S
Max. Continuous Power: 400W
Outside Diameter: 22.4mm
Shaft Diameter: 5mm
Body Length: 17mm
Max. Lipo Cell: 2-4S
ESC: 30-40A
Weight: 21g

Package Included:
1x R1806 2380KV Motor
