Spedix S250Q 280mm Pure Carbon Multirotor Frame Kit
Description:
Brand Name: Spedix
Item name: S250Q Pure Carbon Fiber Frame Kit
Main materials: pure carbon fiber
Main materials: pure carbon fiber
Material: Pure carbon fiber and high strength ABS resin
Shaft distance: 280mm
Dimensions: 260x195x90mm
Dimensions: 260x195x90mm
Weight: 143g (with screws)
The frame comes with newly designed, reinforced landing gears.
This frame is made of carbon fiber central boards and engineering resin arms. The box shaped arm is reinforced with carbon fiber plate in the middle and aluminum columns in the root. Under the motor mount there is a chamber that a round Veltoech 12A ESC specially designed for this frame or a Spedix LED light module can be hidden installed. On the front of the aircraft there are two mounts to install cameras: one face plate for most FPV cameras in the market, and another one on the top with silicone rubber dampers for action cameras. The main frame also provides enough space for control board and FPV equipments. The distance between two central boards is 3.5 cm, around 1 3/8 inches. These designs provide a strong yet light frame to accommodate electronics in a compact space.
Recommend parts (package not include):
Motor: SunnySky X2204S 2300KV
ESC: Spedix round 12A
Propeller: 5-6 inch
Flight Controller: KK2.15 or CC3D
Package included:
1x S250Q Pure Carbon Fiber Frame Kit
Packaging details are as follows:
1x S250Q upper central board
1x S250Q bottom central board
4x Arm covers
1x Carbon fiber upper camera mount (include Damper)
1x Front camera mount
4x Arms
4x Landing gears
The frame comes with newly designed, reinforced landing gears.
This frame is made of carbon fiber central boards and engineering resin arms. The box shaped arm is reinforced with carbon fiber plate in the middle and aluminum columns in the root. Under the motor mount there is a chamber that a round Veltoech 12A ESC specially designed for this frame or a Spedix LED light module can be hidden installed. On the front of the aircraft there are two mounts to install cameras: one face plate for most FPV cameras in the market, and another one on the top with silicone rubber dampers for action cameras. The main frame also provides enough space for control board and FPV equipments. The distance between two central boards is 3.5 cm, around 1 3/8 inches. These designs provide a strong yet light frame to accommodate electronics in a compact space.
Recommend parts (package not include):
Motor: SunnySky X2204S 2300KV
ESC: Spedix round 12A
Propeller: 5-6 inch
Flight Controller: KK2.15 or CC3D
Package included:
1x S250Q Pure Carbon Fiber Frame Kit
Packaging details are as follows:
1x S250Q upper central board
1x S250Q bottom central board
4x Arm covers
1x Carbon fiber upper camera mount (include Damper)
1x Front camera mount
4x Arms
4x Landing gears
