Spedix Round 12A ESC SimonK Program With Red Green LED For 250-300mm Multicopter
Spedix round 12A ESC flashed with SimonK program for 250-300 size multirotors. It is designed to fit and hide in the arms of Spedix S250 quadcopter and hexacopter.
This ESC has a bright red or green LED light to indicate the orientation of a multirotor.
This product does not come with a BEC unit. We recommend to use the Spedix power distribution board to power up receiver and flight controller.
Wires for motor and battery are pre-soldered with 2mm gold plated bullet connectors.
The definition of radio signal wires is brown for ground (-), yellow for signal.
Description:
Continuous Current: 12A(Max 18A@10S)
Voltage Range: 2-4S LiPo
Firmware:SimonK
Dimensions: Φ23x5.5mm(exclude capacitor)
BEC Output: None
Refresh Rate: 600Hz
Motor Wires: 20 gauge soft silicone wires
Battery Wires: 20 gauge soft silicone wires
Weight: 16g (approx. including wires)
Diameter: 28mm (approx. including capacitor)
LED light color: red / green
Flashed with SimonK program,quick response, smooth throttle.
Has a bright red LED light to indicate the orientation of a multirotor.
Package Includes:
1 x Round 12A ESC Red/Green
1 x Round 12A ESC Red/Green
