Spedix KK2.15 Flight Controller LCD Version 2.15 Connected Directly To DSM2 DSMX
Latest generation KK2.15 board with updated sensors, memory, header pins, and hard case protection.can be connected directly to a DSM2/DSMX satellite and S.bus port without using an adapter.
The KK2.15 is next big evolution of the first generation KK flight control boards. The KK2.15 was engineered from the ground up to bring multi-rotor flight to everyone, not just the experts. The LCD screen and built in software makes install and setup easier than ever. A host of multi-rotor craft types are pre-installed, simply select your craft type, check motor layout/propeller direction, calibrate your ESCs and radio and you’re ready to go! All of which is done with easy to follow on screen prompts!
The original KK gyro system has been updated to an incredibly sensitive 6050 MPU system making this the most stable KK board ever and allowing for the addition of an auto-level function. At the heart of the KK2.15 is an Atmel Mega644PA 8-bit AVR RISC-based microcontroller with 64k of memory. An additional polarity protected header has been added for voltage detection, so no need for on-board soldering. A handy piezo buzzer is also included for audio warning when activating and deactivating the board.
The 6 Pin USBasp AVR programming interface ensures future software updates will be quick and easy.
Description:
Dimensions: 50.5x50.5x12mm
Weight: 20g
IC: Atmega644 PA
Gyro/Acc: 6050MPU from InvenSense Inc.
Auto-level: Yes
Input Voltage: 4.8-6.0V
AVR interface: standard 6 pin.
Firmware Version:1.19S1
Features:
1. Based on the original design, but improved with the convenience to connect to a satellite or S.Bus receiver directly, bypassing the requirement of adapter as normal KK board.
2. Engineered from the ground up to bring multi-rotor flight to everyone, not just the experts.
3. The LCD screen and built in software makes install and setup easier than ever.
4. A host of multi-rotor craft types are pre-installed, simply select your craft type, check motor layout/propeller direction, calibrate your ESCs and radio and you’re ready to go!
Package included:
Package included:
1x KK2.15 controller
1x Buzzer
1x Connection cable set
