Main Features:
The flight control supports 1S ( 4.2V ) and 2S ( 8.4V ) power supply, 2S power can bring flying experience more power
Independent design of the circuit structure, comes with the pressure reduction technology, whether it is 1S or 2S power input, UART1 / 2 output 5V, UART3 output 3.3V
Using STM32F303CCT6 + MPU6500, advanced hardware platform F3 guarantee more stable flight
With a large current NMOS transistors, operating current of up to 10A or more. Each machine is equipped with freewheeling diodes
Support for PPM, SBUS, DSM receiver input signal
With battery voltage detection and buzzer interface
In support of the world almost all hollow cup motor, including 1020 coreless motor
Specifications:
Item name: SP RACING F3 EVO Brushed Flight Controller
Dimension: 22 x 32.5mm
Thickness: 1.2mm
Weight: 3g
Notice:
Before applying power, pay attention to the battery voltage selection
The default shipping is 1S ( 4.2V ); 2S first need to disconnect the short contacts 1S, 2S and then connect two pads short. Prohibit the same three pads shorted together
Note: the other gadgets in the picture are not included
The flight control supports 1S ( 4.2V ) and 2S ( 8.4V ) power supply, 2S power can bring flying experience more power
Independent design of the circuit structure, comes with the pressure reduction technology, whether it is 1S or 2S power input, UART1 / 2 output 5V, UART3 output 3.3V
Using STM32F303CCT6 + MPU6500, advanced hardware platform F3 guarantee more stable flight
With a large current NMOS transistors, operating current of up to 10A or more. Each machine is equipped with freewheeling diodes
Support for PPM, SBUS, DSM receiver input signal
With battery voltage detection and buzzer interface
In support of the world almost all hollow cup motor, including 1020 coreless motor
Specifications:
Item name: SP RACING F3 EVO Brushed Flight Controller
Dimension: 22 x 32.5mm
Thickness: 1.2mm
Weight: 3g
Notice:
Before applying power, pay attention to the battery voltage selection
The default shipping is 1S ( 4.2V ); 2S first need to disconnect the short contacts 1S, 2S and then connect two pads short. Prohibit the same three pads shorted together
Note: the other gadgets in the picture are not included
Specifications
General |
Type: Flight Controller |
|---|---|
Dimension and Weight |
Package weight: 0.030 kg
Package size (L x W x H): 6.00 x 3.00 x 1.00 cm / 2.36 x 1.18 x 0.39 inches |
Package Contents |
Package Contents: 1 x Flight Controller, 1 x Connecting Cable |
