Smallest Mini N1 OSD Compatible With Jiyi P2 NAZA Remzibi DJI Phantom 2 FPV Flight Controller
Description:
Weight: about 9g
Weight: about 9g
Appearance of size: 29 * 22 * 9MM
Operating voltage: 4.5-6.5V (through NAZA flight control power supply)
Detection voltage: 2S ~ 6S (6V ~ 26V) (detection image transmission interface voltage)
Working temperature: -20 ~ 75 â
Features:
Mini N1 addition to all the features also included ordinary N1 .Increasing the horizon display,
Increase the low voltage alarm function (single batteries <= 3.6V alarm, 2S-6S automatic recognition)
Low number of satellites alarm (less than 6 satellites)
Support Chinese and English dual-language menu (to facilitate foreign customers)
Beautify the screen font display.
The shell is made of aluminum alloy high-precision CNC machining, work well, better heat dissipation.
Front design has a hole buttons and a LED display, user-friendly OSD Scheduling and viewing status.
Note:
After Mini N1 Power On Self test to enter the main interface, OSD button short click recording time clearing house at the same time,
Under the main screen, press OSD button for two seconds to enter the OSD setup menu, short press for the next one, long press OK.
Package Included:
1 X Mini N1 OSD
Package Included:
1 X Mini N1 OSD
