Skystars BabyTurtle 145MM FPV Racing Drone F4 8K OSD Smartaudio VTX Runcam Split Mini2 DVR Camera
Specification:
Brand name: skystars
Item name: Babyturtle 145MM
Recommend battery: 3-4S 500-800mAH
Drone weight: 144g
Drone size: 130x100x40mm
Package weight: 220g
Package size: 150x150x50mm
| Frame Kit |
Wheelbase: 145mm
Arm Plate Thickness: 3mm
TOP&Bottom Plate Thickness: 1.5mm
Side Plate Thickness: 1.5mm
Material: 3k Carbon Fiber
Weight: 43g
|
| Flight Controller |
Micro F4 Flight Control Board ( D-Shot Version)
MPU: MPU6000-SPI
CPU: STM32F405RGT6, dual 8K.
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A
Size: 25x25mm board, Installing Hole: 20x20mm, mounting holes (M2)
Weight:2.3g
Support Subs/PPM/DSMX receiver
|
| Brushless ESC |
20A 2-4S Blhelis 4 in 1 ESC:
Input Voltage: 2S Lipo battery
Constant Current: 20A
Peak Current: 28A
BEC Ouput: NO
Firmware: BLhelis
Size: 27x27mm (main board) 27x31mm ( including pad)
Installing Hole: 20x20mm, M2
Weight: 4g
MOS Tube: TOP QUALITY MOSFET
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150/300/600, forward and reverse
|
| VTX |
FPV Transmitter
Mini FPV Transmitter
Output power: 25mW/100mW/200mW switchable
Control mode:button OR Channel changes
BAT: 7-26V,BEC 5V-1A
190mA----200mW
Video system: NTSC/PAL
Frequency: 5.8GHz 5 bands 40channels, with Raceband: 5645-5945 MHZ
Size: 24*24mm(L*W),Hole:20*20mm
Weight: 2.5g
|
| Brushless Motor |
skystars 1408 KV 3800, race edition
|
| Camera |
RunCam Split Mini 2 FOV 130 Degree 1080P/60fps HD Recording & WDR FPV Camera NTSC/PAL Switchable
Description:
Brand name: RunCam
Item number: Split Mini 2
Field of View(FOV): FPV FOV 130° / Recording FOV 165°
Video Resolution: 1080@60fps / 1080@30fps / 720@60fps
Video File Format: MOV
Image Resolution: 2 MP
TV Mode: NTSC (720*480) / PAL (720*576) Switchable
Interface : icro USB / UART
Max Micro SD Card Supported: 64G(need Class 6 or above, recommend Class 10 / UHS-I / UHS-II / UHS-III)
Hole Distance of Installation: 20*20mm
Dimensions: PCB 29*29mm / Lens Module 19*19mm
Power Input: DC 5-20V
Working Current: 650mA @5V / 270mA @12V
Weight: 12.5g
|
| Propeller | DALPROP T3056C |
Package Included:
1 x Babyturtle 145mm frame kit
1 x F4 8K Flight Controller
1 x 20A 2-4S Blhelis 4 in 1 ESC
1 x 5.8G 48CH 25mW/100mW/200mW switchable VTX
4 x 1408 KV3800 Motor
1 x RunCam Split Mini 2 DVR Camera
4 x CW DALPROP T3056C Propeller
4 x CCW DALPROP T3056C Propeller
1 x LED X2 BBX1
3 x Battery strap
1 x Brass Antenna
14 x 10.9,12.9 screws
6 x 20MM Aluminum cloum
1 x F4 8K Flight Controller
1 x 20A 2-4S Blhelis 4 in 1 ESC
1 x 5.8G 48CH 25mW/100mW/200mW switchable VTX
4 x 1408 KV3800 Motor
1 x RunCam Split Mini 2 DVR Camera
4 x CW DALPROP T3056C Propeller
4 x CCW DALPROP T3056C Propeller
1 x LED X2 BBX1
3 x Battery strap
1 x Brass Antenna
14 x 10.9,12.9 screws
6 x 20MM Aluminum cloum
