RX LCD5812 5.8GHz 7 Inch Monitor HD LCD Screen Diversity Receiver
RX LCD5812 5.8GHz 7 Inch Monitor HD LCD Screen Diversity Receiver
RX LCD5812 5.8GHz 7 Inch Monitor HD LCD Screen Diversity Receiver
Description:Manual
Model:LCD5812
Name:5.8GHz HD LCD Screen Diversity Receiver
Built-in 5.8Ghz wireless diversity receiver automatically for best reception
Size:180 x 120 x 19.5mm
Color:Black
Color:Black
Integrated sunshield:support(Removable)
Weight:500g(with Sunshield and batery)
LCD Display
View direction:12 O'Clock
View direction:12 O'Clock
LCD size:7.0inch(Diagonal)
Number of Pixer:1024(H) x 600(V)
LCM luminance 500cd/㎡(center point)
View Angle:140/120 degree(Horizontal/Vertical)
5.8GHz Wireless Receiver
Receiving frequency:ISM 5.6GHz-5.95GHz 32 CH
Receive mode: Diversity Receive
Video output Level: IV±0.2Vp-p/75Ω
Audio Output Level:0.5~2.0Vp-p/10KΩ
TV System:PAL/NTSC/AUTO
Antenna Connector:SMA Connector
Antenna Connector:SMA Connector
Wireless Receiver Sensitivity:<-92dBm(15dBuV)
System
Lithium battery:1900mA/7.4V(Removable)
Working Voltage:DC 7~25V
Supply current:<650mA/12V DC
Automatic signal search:support
USB HOST:AV play,photo viewing,software upgrades
HDMI IN:1080P(Max)
AV File Format: MPEG2,MPEG2 _HD, MPEG4,MPEG4_SD,MPEG4_HD,H.264
Interface
AV IN:2.5 x 1
AV IN:2.5 x 1
AV OUT:2.5 x 1 (RF A OUT/RF B OUT and Diversity OUT)
HDMI IN:TYPE C x (support Hot plug)
USB:Micro USB x 1
DC IN: OD/ID:3.5/1.2mm x 1
5.8GHzANT:SMA x 2
Feastures:
Package Included:
1 x 5.8GHz HD LCD Screen Diversity Receiver
Feastures:
Package Included:
1 x 5.8GHz HD LCD Screen Diversity Receiver
