RunCam Swift Mini 2 + Mini DVR Remote Control 600TVL 2.1mm/2.3mm 1/3" CCD One Touch Scene Setting FPV Camera
Specification:
Model: RunCam Swift Mini 2
Image Sensor: 1/3" SONY Super HAD II CCD
Horizontal Resolution:600TVL
Lens: 2.1mm ?(M12)? FOV165° / 2.3mm(M12) FOV 150°
Signal System: PAL / NTSC
Integrated OSD: Yes
One Key Scene: Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight
S/N Ratio: >60dB (AGC OFF)
Electronic Shutter Speed: PAL: 1/50~100,000; NTSC: 1/60~100,000
Auto Gain Control (AGC): Yes
Min. Illumination: [email protected]
WDR: D-WDR
DNR: 2DNR
Day/Night: Color/Auto/B&W
Power: DC 5-36V
Current: 120mA@5V / 60mA@12V
Net Weight: 12g
Dimensions: L22.3mm*W22mm*H26mm
Features:
With integrated OSD
One Touch Scene Setting(5 preset scenes)
Item name: Mini FPV DVR Module
Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g
Remote Control Version
Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording.
Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)
Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)
Method 2. Manual association
Open the App (iOS >= 1.0.8, Android >= 1.0.7)=> select the Help Center=>click RunCam DVR-S => select Telemerty Control
Features:
* Designed for Mini FPV Racing Drone! ( 25*25mm @ 20*20mm M2 holes)
* Lossless video output for VTX! (Since it has been loaded to the DVR, it needs to synchronize the video amplification output)
* Black technology! Can record high-frequency vibration motor audio without access to MIC!
Package included:
1x Runcam Mini FPV DVR Module
1 x Runcam Mini Swift 2Camera
1 x Aluminum bracket
1 x ABS bracket
1 x Set of screws
1 x 6pin FPV silicone cable
1 x OSD Key-press Board
1 x 3pin FPV silicone cable
1 x Manual
