RunCam Racer 2 + Mini DVR Remote Control Super WDR CMOS 700TVL 1.8mm/2.1mm fpv Camera 6ms Low Latancy OSD With Selector Switch
Description
RunCam Racer 2 Camera
User Manual :https://www.runcam.com/download/Racer2-Manual.pdf?t=20181127
Mini FPV DVR Module
Package Included:
1x Runcam Racer 2 Camere
1x Runcam Mini FPV DVR Module
Description
RunCam Racer 2 Camera
| Model | RunCam Racer 2 | ||
| Image Sensor | Super WDR CMOS Sensor | ||
| Horizontal Resolution | 700TVL | ||
| Lens |
|
||
| Screen Format | 4:3 / Widescreen Switchable | ||
| Signal System | NTSC / PAL Switchable | ||
| Mirror/Flip | Available | ||
| Integrated OSD | Yes | ||
| One Touch Scene Setting | Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight | ||
| S/N Ratio | >50dB | ||
| Electronic Shutter Speed | Auto | ||
| Min. Illumination | [email protected] | ||
| WDR | Super WDR | ||
| Day/Night | Auto | ||
| Menu Control | Joystick Control / UART Control Switchable | ||
| Power | DC 5-36V | ||
| Current | 110mA@5V / 40mA@12V | ||
| Housing Material | ABS | ||
| Net Weight | 5.5g | ||
| Dimensions | L19mm*W19mm*H18mm |
User Manual :https://www.runcam.com/download/Racer2-Manual.pdf?t=20181127
Mini FPV DVR Module
Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA(640 x 480) @ 30fps(NTSC)/25fps(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g
Remote Control Version
Using the Speedy Bee App to set the Remote control function, you can start/stop recording through the remote control. For example, you can bind the recording function to the ARM mode, and the DVR will start recording when the ARM mode is activated. Otherwise, the DVR will stop recording.
Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)
Method 1. Automatic association (App iOS >= 1.0.8, Android >= 1.0.7)
Method 2. Manual association
Open the App (iOS >= 1.0.8, Android >= 1.0.7)=> select the Help Center=>click RunCam DVR-S => select Telemerty Control
Features:
* Designed for Mini FPV Racing Drone! ( 25*25mm @ 20*20mm M2 holes)
* Lossless video output for VTX! (Since it has been loaded to the DVR, it needs to synchronize the video amplification output)
* Black technology! Can record high-frequency vibration motor audio without access to MIC!
Package Included:
1x Runcam Racer 2 Camere
1x Runcam Mini FPV DVR Module
