RunCam PZ0420M-L28 2.8mm 600TVL 86 Degree 1/3 CCD FPV Camera IR Block 5-17V NTSC PAL - 30.79 €

RunCam PZ0420M-L28 2.8mm 600TVL 86 Degree 1/3 CCD FPV Camera IR Block 5-17V NTSC PAL
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


RunCam PZ0420M-L28 2.8mm 600TVL 86 Degree 1/3 CCD FPV Camera IR Block 5-17V NTSC PAL













Specification:
Brand name: Runcam
Image Sensor: 1/3 SONY SUPER HAD II CCD
Horizontal Resolution: 600TVL
Effective Pixel: PAL:753(H)*582(V), NTSC:768(H)*494(V)
Signal System: PAL/NTSC
Synchronization: Internal
Auto White Balance: Manual/Auto/Auto tracking
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL: 1/50 to 1/100,000sec; NTSC: 1/60 to 1/100,000
Auto Gain Control: off/low/mid/high optional
Back light compensation (BLC) : off /BLC/ anti-exposure
Motion Detection (MD): On/Off (multi-level sensitivity)
Min. Illumination: 0.01Lux/1.2F
Shading Area: 8
Video Output:1.0Vp-p 75 ohm RCA output
Power: DC 5 to 17V
Negative/ positive: Negative/ positive optional
Edge light compensation: Yes
Display Mode: LED monitor/CRT monitor
Synchronize IR turn on and color turn to B&W: Yes (optional)
IR image optimize: Anti exposure of the object in the middle
DNR: 2DNR
Day/ Night Switch: Auto/ Color/ B&W/ Outside control (position start and end controllable)
Day/ Night time switch: 1 to 30 Switchable time
OSD: Chinese/ English Menu
White dot repair (DPC): Yes
Image adjust: Yes
Function Control: OSD
Dimensions: 28mm * 28mm(PZ0420M)
Operating Voltage:5.0V 12.0V 17.0V
Supply current: 170mA 50mA 30mA
Operation Temp: –10C to +50C
Operation Environ.: 10% to 90%
Weight: 18g


Feature:
Color 600TVL Black & white 650TVL High Picture Quality
1/3'' SONY SUPER HAD II CCD
Support 2 to 4S battery (DC 5 to 17V) Wide voltage Power input
2.8mm wide angle lens
Removable 5D OSD menu
Digital Wide Dynamic Range(D-WDR)
Digital Noise Reduction(2 DNR)
Low Power Consumption
Back light compensation (BLC)
MIRROR
Anti-exposure function support car license recording(HLC)
Low illumination:0.01Lux
White dot repair(DPC)
CVBS(RCA) Video output

User Manual, .

Package Included:
1 X Camera
1X OSD Menu
1X Cable
1X FPV Cable
1X Manual
