RunCam PZ0420M-L24 2.4MM 120°3M 600TVL DC 5-17V Wide Voltage Mini FPV Camera
2.4MM VS 2.8MM:
Description: User Manual
Brand Name: RunCam
Item NO.: PZ0420M-L24
Image Sensor: 1/3 SONY SUPER HAD II CCD
Horizontal Resolution: 600TVL
Effective Pixel: PAL:753(H)*582(V), NTSC:768(H)*494(V)
Signal System: PAL/NTSC
Synchronization: Internal
Auto White Balance: Manual/Auto/Auto tracking
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL: 1/50 to 1/100,000sec; NTSC: 1/60 to 1/100,000
Auto Gain Control: off/low/mid/high optional
Back light compensation (BLC): off /BLC/ anti-exposure
Motion Detection (MD): On/Off (multi-level sensitivity)
Min. Illumination: 0.01Lux/1.2F
Shading Area: 8
Video Output: 1.0Vp-p 75 ohm RCA output
Power: DC 5 to 17V
Supply current: 170mA-30mA
Operation Temp.: –10C to +50C
Operation Environ.: 10% to 90%
Edge light compensation:Yes
Display Mode: LED monitor/CRT monitor
IR image optimize: Anti exposure of the object in the middle
DNR: 2DNR
Day/ Night Switch: Auto/ Color/ B&W/ Outside control (position start and end controllable)
Day/ Night time switch: 1 to 30 Switchable time
OSD: Chinese/ English Menu
White dot repair (DPC): Yes
Image adjust: Yes
Function Control: OSD
Board Size: 28 x 28mm
Weight: 12G
Suitable for Fixed-wing Aircraft, Multirotor like QAV250 etc.
Features:
Color 600TVL Black & white 650TVL High Picture Quality
1/3'' SONY SUPER HAD II CCD
Support 2 to 4S battery (DC 5 to 17V) Wide voltage Power input
Removable 5D OSD menu
Digital Wide Dynamic Range(D-WDR)
Digital Noise Reduction(2 DNR)
Low Power Consumption
Back light compensation (BLC)
MIRROR
Anti-exposure function support car license recording(HLC)
Low illumination:0.01Lux
White dot repair(DPC)
CVBS(RCA) Video output
Package Included:
1 x Camera
1 x OSD Menu
1 x Cable
1 x FPV Cable
1 x Manual
