Aphid
The multicopter of Aphid, the materials use of high strength black fiberglass, CNC precision cutting, standard 450 wheelbase,dont' need worry about the multicopterto find the center of gravity, to fly with the standard wheelbase shaped body, stable, simple.
(This product except the camera modules, does not contain any other electronic products and accessories)
Are you still worry about the space of 450 is not enough? Are you still worry about the gravity of rack? Please select Aphid, the unique modular design, it can be replaced, more expansion holes, facilitate post product upgrades. Standard 450 wheelbase, the center of gravity positioning is simple and quick to support the arm height tripod and body tripod, flexible. Supports multiple flight control installation. As you install the rear fuselage, the same to battery.Flight stabilization stay a long time to set aside ultrasonic module mounting holes.
The rack of camera module has been replaced with a higher resolution camera, to ensure clear video when FPV flight, can also be based on personal preferences, change FPV cameras, supports the size is 32 * 32cm and 38 * 38cm of the camera installation.
The rack of head comes with GOPRO mounting plate can be replaced GOPRO HD camera shoot.
This product except the camera modules, does not contain any other electronic products and accessories
Specification:
Arm/Wing:3mm F450 nylon arm
Center board maetrial:Black glass fiber
Wheel base:450mm
Weight:350g
Flight weight:800g-1200g
Landing skid not included,pls purchase saparately
The high tripod is shown separately, are not included in the product. This product except the camera modules, does not contain any other electronic products and accessories.
Recommend configuration 1(not included)
4 x 2212 motor
4 x Hobbywing SkyWalker 20A Brushless ESC
4 x 1047 CW CCW propeller
1 x WFT07 transmitter
1 x Rabbit /AMP Flight Control Board
1 x 3S 2200mHA Lipo battery / 4000mHa Lipo battery
1 x FVP 5.8G 200mW
Recommend configuration 2(not included)
4 x 2216 kv900 or kv800 motor
4 x Hobbywing SkyWalker 40A Brushless ESC
4 x 1047 CW CCW propeller
1 x WFT09 transmitter
1 x Rabbit /AMP/NAZA Flight Control Board
1 x 3S 4000mHA Lipo battery /4S 4000mHa Lipo battery
1 x FVP 5.8G 500mW
Package Included:
1 x Rack of X450
1 x Camera module
1 x Manual
