Reptile550-V2 Quadcopter Frame Kit Multicopter with Tall Landing Skid Gear
Description:
Suit 45 * 45mm flight control board (FF, kk, rabbit, pirate, MWC, etc.)
With Extend board, the ESC parallel plates or 4-in-1 ESC can be installed on it.
With mounting holes for ultrasonic board, special design for installing NAZA flight control (long hole left for VELCRO to fix the controller), holes for tall landing skill.
2200 mAh battery can be fixed at the end of the lower plate. (Move the battery backward or forward to balance the weight of the PTZ).
Center upper plate: with cross holes for mounting NAZA GPS and aluminum mounting plate (38 * 38/33 * 33) in front of it for FPV camera.
Transmitter or remote control receiver and other components can be set at the end of the plate.
Arms: similar arms with F450, F550
Biggest propeller can be used: 12-inch, usually we use 10.11 inch ones
Recommended motor: 2212.2216.4006.5005
Specification:
Wheelbase:500mm
Min Arm distance:380mm
Max Arm distance:480mm
Material:Glassfiber+ ABS Plastic
Color:Red+White+Black
Weight:485g
With Tall landing Skid
Note: Kit only,not assembled.
Package includes:
1 x Frame Set
1 x Pack Mounting screws
2 x Aluminum column
1 x Landing Skid set
