Eachine TOTG01 PPM Data Transmission Virtual Joystick 3-in-1 Transceiver Combo For Smartphone Laptop
This 3-in-1 transceiver set includes 3 main functions of PPM, data transmission and virtual joystick . There are PPM and SBUS ports on RF module, can shift channels on remote controller easily. Its transmitter can be used as data transceiver on ground station ,and display the flight data on smartphone or laptop which support android, windows or macos system. Its transparent transmission can be widely compatible with all flight controllers on market . Last but not least, you can control the drone with virtual joystick on APP, or mix-control it by APP and Remote Transmitter. In mix-control mode, 1-6CH are controlled by PPM, and the 7-8CH (which can be headtracker channels)are controlled by APP. It will be fun that when you control the drone and your partner can control the gimbal pan and tilt by shaking the phone.
Description
Model : OTG FPV Multi-Functional RF
Frequency : 2.4-2.48Ghz
Channel : 8CH
Frequency Hopping : FHSS
Distance : 2-5km
Support System : Android,Windows,macos
Connection : Bluetooth,USB
Connector : RP-SMA
Dimension : 70*41*10.8mm
Weight : 18.3g(without antenna)
Power Supply
Transmitter
USB : 5V,can be powered by smartphone,laptop or power bank etc.
PPM : 5-12V, red-positive,black-GND,yellow-PPM IN
Working Current : 80mA/60mA
Receiver : Power by BEC or Flight Controller, 5V
3 Functions (long press button 2 to switch functions)
PPM Transmission : (red LED on,if it flashes--signal fail)
Data transmission : connect with smartphone or laptop to build up a ground station.(red and green LEDs on)
Virtual joysticks(support android only) : can control the rc drone by APP, or use it as a headtracker (green LED on,if it flashes--connecting fail)
APP Download : http://app.mi.com/details?id=com.shenyaocn.android.virtualjoystick
Lost Control Protection
Default : 124CH : 1500/3CH: 900/ 5-8CH : maintain
Long press button 1, the main module will record the instantaneous data on APP or PPM, if successes,LED will flash. Please adjust the data before you press it.
Connections
1. USB connect to Android Smartphone(support OTG and APP), random baud rate
2. USB connect to PC, require to install the stm2 seriel port device , random baud rate
3. Bluetooth(doesn't support iPhone iPad), search BT and match, the match code is 1234, and turn on APP to connect it.(notice: either wired or BT, can't use both )
Rebinding
When you use another receiver, you should rebind it at first.
Power off the transmitter, and power on the receiver, long press the "set" button, green LED flashes, then power on the transmitter, receiver LED lighting, success.
Package Included
1 x Transmitter
1 x Receiver
1 x Antenna
2 x OTG Cable
1 x 3P PPM Cable
