Realacc RX5809 5.8G 48CH Diversity FPV Receiver For Fatshark Goggles
Description :
Brand Name : Realacc
Item Name : RX5809
POWER SUPPLY : 3.3V--5.0V
Current Consumption : 180mA , Max
Operating Temperature : -10°-+65°
Operating Humidity : 85%RH
Receiving Frequency Range : 5362 ~ 5945MHz 48CH
Receiving Sensitivity : -90dBm
Video Output Impedance : 75C, Typ.
Video Output Level : 1Vp-p, Typ.
Audio Output Level : 1±0.2Vp-p, Typ.
Audio Carrier : 6.0MHz(AR), 6.5MHz(AL)
Weight : 11g
Dimension : 41.9*24.75*18.47 mm
Operating Guide
Band is set by a 3 dip-switch.
Band SW1 SW2 SW3
Band1 ON OFF OFF
Band2 OFF ON OFF
Band3 OFF OFF ON
Band4 OFF OFF OFF
Band5 ON ON ON
Band6 OFF ON ON
Channel is set by 3 control pins of connector, "1" is high level.
Channel CS1 CS2 CS3
CH1 0 0 0
CH2 0 0 1
CH3 0 1 0
CH4 0 1 1
CH5 1 0 0
CH6 1 0 1
CH7 1 1 0
CH8 1 1 1
Frequency :
CH1 CH2 CH3 CH4 CH 5 CH6 CH7
Band 1 5865 5845 5825 5805 5785 5765 5745
Band 2 5733 5752 5771 5790 5809 5828 5847
Band 3 5705 5685 5665 5645 5885 5905 5925
Band 4 5740 5760 5780 5800 5820 5840 5860
Band 5 5658 5695 5732 5769 5806 5843 5880
Band 6 5362 5399 5436 5473 5510 5547 5584
Package Included :
1 x Receiver
