Realacc PDB-XPW 5V 12V Dual BEC PDB Built-in 150A Current Sensor with XT60PW Socket - 5.99 €

The PDB-XPW distributes power from a LiPo pack to 4 ESCs, as well as providing synchronised & regulated DC 5V outputs & linear regulated DC 12V for powering Cameras, RC receiver, Flight Controllers, Video Transmitters, LEDs, etc.It also has built-in 150A current module, and offers a XT60PW socket to connect the LiPo pack conveniently.

General:

-Input voltage range (3S-5S LiPo operation): 9 - 21V DC

-PDB: 4 x 35A

-Regulated 5V and 12V outputs

-Current module 150A

-LED power indicators ( 5V & 12V outputs )

Current Module

- 150A

-3.3V ADC

BEC 5V output:

-Designed for RC Receivers, Flight controllers, OSD, and Servos.

-DC/DC synchronous buck regulator.

-Voltage: 5.0 +/- 0.1VDC

-Continuous current: 2 Amps (Max.2.5A 10s/minute)

-Output Ripple: 40mV (VIn=16V, VOut=5V@2A load)

-Short-circuit tolerant (5 seconds/minute)

BEC 12V output:

-Designed for Video TX or FPV camera with linear regulator.

-The battery should be 4~5S LiPo (13~21V DC)

- Voltage: 12.0 +/- 0.3VDC

-Continuous current: 500mA (Max.0.8A 5s/minute)

-Short-circuit tolerant (2 seconds/minute)

BEC 12V @ 3S LiPo

-Output voltage= 3S LiPo voltage -1V

Physical:

-Mounting: 30.5 x 30.5mm, Φ3mm

-Dimensions: 36 x 50 x 4 mm (w/o XT60PW), 36 x 58 X10.5mm (w/ XT60PW)

-Weight: 7.0g(w/o XT60PW), 11g(w/ XT60PW)
