Realacc 5.8G 5dBi 50W Omnidirectional Omni FPV Flat Panel Pagoda Antenna LHCP/RHCP SMA/RP-SMA - 8.99 €

Realacc 5.8G 5dBi 50W Omnidirectional Omni FPV Flat Panel Pagoda Antenna LHCP/RHCP SMA/RP-SMA
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Realacc 5.8G 5dBi 50W Omnidirectional Flat Panel Antenna Omni Tower Plated FPV Antenna SMA/RP-SMA
Thanks the designer Maarten baert, who gives the idea, if you want more information, pls click :http://www.maartenbaert.be/quadcopters/antennas/pagoda-antenna/






Description :
Brand Name : Realacc
Item Name : Omnidirectional Antenna
Gain : 5dBi
Max. Power : 50w
Connector : RP-SMA,SMA
Color : Black, Red, White
Weight : 8.6g
Length : 78±3mm
Max. Dia. : 22.4±1mm
Min. Dia. : 11.8±1mm
Specification :
Frequency : 5.8G
Impedance : 50Ω
VSWR : <1.5:1
Polarization : Vertical
Radiation : Omni
Features :
Omni-directional, no dead corner
High gain, more stable.
Less flash, stonger siginal
Package Included :
1 x Antenna
