RCX Simonk 10A ESC Brushless Motor Speed Controller For Multicopter
Description:
Brand: Simonk
Item name: 10A ESC
Continuous current: 10A
Burst current: 13A
BEC: 5V 2A
Input Voltage: 2-3S Li-Po Battery
Input Voltage: NiMH NiCd 6-16.8V
Signal frequency compatible: 30Hz - 499Hz
Size: 26mm (L) x 23mm (W) x 7mm (H)
Weight: 12g
MCU: Atmega
Designed for: Multicopter
Suitable SimonK Firmware: tgy.hex (if you want to flash it by yourself)
4S Battery is possible if the current drawing from the ESC is not too high.
Keep it below 8A should be safe.
Note:
Please do not drive this ESC more than 13A current, it will burn!
Package included:
1 x Simonk 10A ESC
