RCTIMER 30A BLHeli OPTO Mini Brushless ESC Speed Controller For Quadcopter Multicopter
Description:
Description:
Voltage: 2 - 6S LiPo
Output Current: 30A
BEC: Without
Output PWM frequency:18KHz
Firmware:BLHeli 13.2
Weight:11g(without wires)
Size:45*16.6*5.5mm
Features:
oneshot and damped light both enabled!
Specially for Multi-copter, throttle respond fast;
Suit for throttle, which can compatible well with motor;
Throttle signal is twisted pair cable, reduce the crosstalk while the signal transfer by the copper wire and flight more stable;
Use new process ultra-low resistance MOSFET with miniaturization, and all flashes are N MOS with high withstanding current;
Minaturization design, Mini30A with high performance capacitor fliter on the board, also already thicken the PCB copper specially and low heat for small aircraft.
Package Included:
1 x RCTIMER 30A Brushless ESC
